EATON Molded Case Circuit Breaker: 90 A Amps, 65kA at 240/277V AC, Fixed, ABC - FD-Frame Eaton Molded Case Circuit Breakers
EATONFD-Frame Eaton Molded Case Circuit Breakers

EATON Molded Case Circuit Breaker: 90 A Amps, 65kA at 240/277V AC, Fixed, ABC

The EATON FD3090 is a 90 A FD-frame molded case circuit breaker from the EATON FD series. It features a fixed trip unit, ABC phase protection, and a 65kA interrupting rating at 240/277V AC. This unit is equipped with…

SKU 3G-OTH-151003

Brand
EATON
Item
Molded Case Circuit Breaker: 90 A Amps, 65kA at 240/277V AC, Fixed, ABC
Category
FD-Frame Eaton Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
FD3090
Type
65kA at 240/277V AC, Fixed, ABC, Load Side Lug, Std
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON FD3090 is a 90 A FD-frame molded case circuit breaker from the EATON FD series. It features a fixed trip unit, ABC phase protection, and a 65kA interrupting rating at 240/277V AC. This unit is equipped with load-side lugs and is rated for a 225A frame size.

Frequently Asked Questions

What is the EATON FD3090 molded case circuit breaker used for?

The EATON FD3090 is a 90 A molded case circuit breaker designed for branch circuit protection in commercial and industrial power distribution systems. It safeguards wiring and equipment against overloads and short circuits, with a 65kA interrupting rating at 240/277V AC for high-fault applications.

What are the specifications of the EATON FD3090 circuit breaker?

The EATON FD3090 is a 90 A, FD-frame breaker with a fixed trip unit, ABC phase protection, and a 65kA interrupting rating at 240/277V AC. It includes load-side lugs and is rated for a 225A frame size. The part number is FD3090, and it is part of the EATON FD series.

Where to buy the EATON FD3090 circuit breaker worldwide?

3G Electric supplies the EATON FD3090 molded case circuit breaker worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this Eaton FD-series breaker.

How to install the EATON FD3090 circuit breaker?

Install the EATON FD3090 by mounting it on a DIN rail or panel, connecting line and load conductors to the load-side lugs, and torquing terminals to manufacturer specifications. Always de-energize the system before installation and follow local electrical codes. Consult the Eaton FD-series manual for detailed instructions.
