EATON Roller Lever Plunger Limit Switch: LS-Titan Series, 1NO/1NC - Lever- & Roller-Actuated Safety-Interlock Switches
EATONLever- & Roller-Actuated Safety-Interlock Switches

EATON Roller Lever Plunger Limit Switch: LS-Titan Series, 1NO/1NC

The EATON LS-Titan Series Roller Lever Plunger Limit Switch (MPN LSM-11S-RLA) is a lever- and roller-actuated safety-interlock switch with a 1NO/1NC contact configuration. It features momentary/momentary switch…

SKU 3G-OTH-31788

Brand
EATON
Item
Roller Lever Plunger Limit Switch: LS-Titan Series, 1NO/1NC
Category
Lever- & Roller-Actuated Safety-Interlock Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
LSM-11S-RLA
Series
LS-Titan
Switch Action
Momentary/Momentary
Terminal Connection Type
Cage Clamp
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON LS-Titan Series Roller Lever Plunger Limit Switch (MPN LSM-11S-RLA) is a lever- and roller-actuated safety-interlock switch with a 1NO/1NC contact configuration. It features momentary/momentary switch action and cage clamp terminal connections for secure wiring.

Frequently Asked Questions

What is the EATON LS-Titan roller lever limit switch used for?

The EATON LS-Titan roller lever limit switch (LSM-11S-RLA) is used for position sensing and safety interlocking in industrial machinery. It detects the presence or absence of moving parts, such as conveyor belts or machine guards, and sends a signal to control systems to stop or start equipment.

What are the specifications of the EATON LSM-11S-RLA limit switch?

The EATON LSM-11S-RLA is part of the LS-Titan series. It has a 1NO/1NC contact configuration with momentary/momentary switch action. The terminal connection type is cage clamp for secure wiring. It is a roller lever plunger limit switch designed for industrial safety applications.

Where to buy EATON LS-Titan limit switches worldwide?

You can source the EATON LS-Titan limit switch (LSM-11S-RLA) from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead times.

How to install an EATON LS-Titan roller lever limit switch?

Mount the EATON LS-Titan switch securely using the provided mounting holes. Connect wires to the cage clamp terminals, ensuring proper polarity and torque. Adjust the roller lever position to align with the actuator. Test the switch action to confirm correct operation before use.
