EATON Limit Switch Lever Arm: Roller Lever, Fixed, 1.5 in Arm/Operator Lg - Max - Roller Levers for Limit Switches
EATONRoller Levers for Limit Switches

EATON Limit Switch Lever Arm: Roller Lever, Fixed, 1.5 in Arm/Operator Lg - Max

The EATON E50KL25 is a roller lever arm for limit switches, featuring a rotary lever roller actuator with an inside offset roller position. It is compatible with the EATON E50 series and has a fixed arm/operator…

SKU 3G-OTH-30107

Brand
EATON
Item
Limit Switch Lever Arm: Roller Lever, Fixed, 1.5 in Arm/Operator Lg - Max
Category
Roller Levers for Limit Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
E50KL25
Type
Fixed, 1.5 in Arm/Operator Lg - Max, E50
Actuator Style
Rotary Lever Roller
Roller Position
Inside Offset
Compatible with Series
E50
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON E50KL25 is a roller lever arm for limit switches, featuring a rotary lever roller actuator with an inside offset roller position. It is compatible with the EATON E50 series and has a fixed arm/operator length of 1.5 inches maximum. This component is designed for use as a replacement or accessory lever arm in industrial limit switch applications.

Frequently Asked Questions

What is the EATON E50KL25 limit switch lever arm used for?

The EATON E50KL25 is a roller lever arm used as a replacement or accessory for EATON E50 series limit switches. It features a rotary lever roller actuator with an inside offset roller position, designed to detect the position of moving machinery parts in industrial automation and material handling applications.

What are the specifications of the EATON E50KL25?

The EATON E50KL25 has a rotary lever roller actuator style with an inside offset roller position. It is compatible with the EATON E50 series limit switches and has a fixed arm/operator length of 1.5 inches maximum. The manufacturer part number is E50KL25.

Where to buy the EATON E50KL25 worldwide?

You can source the EATON E50KL25 through 3G Electric, a global industrial equipment distributor established in 1990. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this EATON limit switch lever arm.

How to install the EATON E50KL25 roller lever on a limit switch?

To install the EATON E50KL25, first ensure the limit switch is de-energized. Remove the existing lever arm by loosening the mounting screw. Align the E50KL25's rotary lever roller actuator with the switch shaft, then tighten the screw to secure the fixed arm. Verify free movement of the roller before re-energizing.
