EATON Definite Purpose Magnetic Contactor: 2 Poles, 208-240V AC, 25 A - Non-Reversing Definite Purpose Contactors
EATONNon-Reversing Definite Purpose Contactors

EATON Definite Purpose Magnetic Contactor: 2 Poles, 208-240V AC, 25 A

The EATON C25 Series Definite Purpose Magnetic Contactor (MPN C25BNB225B) is a non-reversing, 2-pole contactor with a 2NO main pole contact form. It features a 208-240V AC coil voltage, a maximum voltage rating of…

SKU 3G-OTH-41502

Brand
EATON
Item
Definite Purpose Magnetic Contactor: 2 Poles, 208-240V AC, 25 A
Category
Non-Reversing Definite Purpose Contactors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
C25BNB225B
Series
C25 Series
Type
25 A, Non-Reversing
AC
208-240V
Phase
Single
Frame Size
B
Coil Voltage
208-240V AC
Contactor Style
HVACR Definite Purpose Contactor
Main Pole Contact Form
2NO
Maximum Voltage Rating
690V AC
Terminal Connection Type
Quick-Disconnect Terminals
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON C25 Series Definite Purpose Magnetic Contactor (MPN C25BNB225B) is a non-reversing, 2-pole contactor with a 2NO main pole contact form. It features a 208-240V AC coil voltage, a maximum voltage rating of 690V AC, and quick-disconnect terminals. This HVACR definite purpose contactor is designed for single-phase applications in the C25 Series, Frame Size B.

Frequently Asked Questions

What is the EATON C25BNB225B definite purpose contactor used for?

The EATON C25BNB225B is a definite purpose magnetic contactor designed for HVACR applications such as air conditioning, refrigeration, and heating systems. It controls single-phase motor loads up to 25 A with a 208-240V AC coil, making it suitable for compressors, fans, and pumps in commercial and industrial environments.

What are the specifications of the EATON C25BNB225B contactor?

The EATON C25BNB225B is a 2-pole, non-reversing contactor with a 208-240V AC coil voltage and 25 A rating. It has a maximum voltage rating of 690V AC, quick-disconnect terminals, and a 2NO main pole contact form. It belongs to the C25 Series, Frame Size B, and is designed for single-phase applications.

Where to buy the EATON C25BNB225B contactor worldwide?

You can source the EATON C25BNB225B contactor worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we provide reliable sourcing for EATON C25 Series components.

How to install the EATON C25BNB225B definite purpose contactor?

To install the EATON C25BNB225B, ensure power is off and the coil voltage matches your 208-240V AC supply. Mount the contactor securely using the frame B footprint, connect wires to the quick-disconnect terminals, and verify the 2NO contacts are properly aligned. Follow standard HVACR wiring practices and consult the manufacturer's manual for torque specifications.

Used in

Common applications for EATON
Industrial control panels — Eaton M22 flush push buttons for momentary machine start/stop commands
Motor control centers — Eaton NEMA reversing starters with electronic overloads for conveyor belt direction control
HVAC systems — Eaton definite purpose starters with thermal overloads for compressor and fan motor protection
Process automation — Eaton SL7 tower lights with IP66 bases for visual status indication in wet environments
Machine tool signaling — Eaton 10250T LED pilot lights with push-to-test for operator panel status lamps
Access control — Eaton M22 keyed selector switches for equipment mode selection in secured areas
