EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, Electronic Protection, 25 A - Enclosed, Non-Reversing Starters with Electronic Overloads
EATONEnclosed, Non-Reversing Starters with Electronic Overloads

EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, Electronic Protection, 25 A

The EATON IEC Magnetic Motor Starter is an enclosed, non-reversing starter with electronic overloads, model ECX09G1AAA-R63/D. It features 3 poles, electronic protection, a 25 A rating, and 120V AC operation. The unit…

SKU 3G-OTH-45235

Brand
EATON
Item
Magnetic Motor Starter: Non-Reversing, 3 Poles, Electronic Protection, 25 A
Category
Enclosed, Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
ECX09G1AAA-R63/D
Type
Electronic Protection, 25 A
AC
120V
Poles
3
Pilot Lights Included
None
Auxiliary Contacts Included
1NO/1NC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON IEC Magnetic Motor Starter is an enclosed, non-reversing starter with electronic overloads, model ECX09G1AAA-R63/D. It features 3 poles, electronic protection, a 25 A rating, and 120V AC operation. The unit includes 1NO/1NC auxiliary contacts and no pilot lights.

Frequently Asked Questions

What is the EATON IEC Magnetic Motor Starter used for?

The EATON IEC Magnetic Motor Starter is used to start and stop three-phase motors in industrial applications. It provides electronic overload protection to prevent motor damage from overcurrent. Typical uses include conveyors, pumps, fans, and compressors in manufacturing and process industries.

What are the specifications of the EATON ECX09G1AAA-R63/D motor starter?

The EATON ECX09G1AAA-R63/D is a non-reversing, enclosed motor starter with 3 poles and electronic overload protection. It is rated for 25 A and operates on 120V AC. It includes 1NO/1NC auxiliary contacts and has no pilot lights. The brand is EATON.

Where to buy the EATON ECX09G1AAA-R63/D motor starter worldwide?

You can source the EATON ECX09G1AAA-R63/D motor starter from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to select the correct EATON motor starter for a motor?

To select the correct EATON motor starter, match the starter's full-load current rating (25 A for this model) to the motor's nameplate current. Ensure the coil voltage (120V AC) matches your control circuit. The electronic overload provides adjustable protection. Consult EATON's selection guide for motor horsepower equivalents.
