EATON Overload Relay: Electronic Protection, 3 Poles, 1NO/1NC, Phase Loss Sensitivity - IEC Electronic Overload Relays
EATONIEC Electronic Overload Relays

EATON Overload Relay: Electronic Protection, 3 Poles, 1NO/1NC, Phase Loss Sensitivity

The EATON Overload Relay: Electronic Protection (MPN XTOE045CGS) is an IEC electronic overload relay in Frame Size C, designed for use with EATON XT Mini Contactors of the same frame size. It features 1NO/1NC…

SKU 3G-OTH-44811

Brand
EATON
Item
Overload Relay: Electronic Protection, 3 Poles, 1NO/1NC, Phase Loss Sensitivity
Category
IEC Electronic Overload Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
XTOE045CGS
Type
1NO/1NC, Phase Loss Sensitivity, Frame Size C
Poles
3
Frame Size
C
Compatible Contactors
Frame Size C
Auxiliary Contact Form
1NO/1NC
Phase Loss Sensitivity
Yes
Thermal Units Required
Not Applicable to Electronic Type Overload Relays
Compatible Contactor Series
XT Mini Contactors
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Overload Relay: Electronic Protection (MPN XTOE045CGS) is an IEC electronic overload relay in Frame Size C, designed for use with EATON XT Mini Contactors of the same frame size. It features 1NO/1NC auxiliary contacts and phase loss sensitivity, with no thermal units required as it is an electronic type.

Frequently Asked Questions

What is the EATON XTOE045CGS overload relay used for?

The EATON XTOE045CGS is an IEC electronic overload relay that protects three-phase motors from overload, phase loss, and other electrical faults. It is designed for use with EATON XT Mini Contactors in Frame Size C, making it suitable for industrial motor control applications across manufacturing, HVAC, and pumping systems.

What are the specifications of the EATON XTOE045CGS overload relay?

The EATON XTOE045CGS is a 3-pole electronic overload relay with 1NO/1NC auxiliary contacts and phase loss sensitivity. It is Frame Size C, compatible with EATON XT Mini Contactors of the same frame size. No thermal units are required as it uses electronic protection. The manufacturer part number is XTOE045CGS.

Where to buy the EATON XTOE045CGS overload relay worldwide?

3G Electric supplies the EATON XTOE045CGS overload relay to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us for pricing and lead time on this electronic protection relay for motor control applications.

How to select the correct EATON overload relay for a contactor?

Select an EATON overload relay that matches the frame size of your contactor. The XTOE045CGS is Frame Size C and works with EATON XT Mini Contactors of the same frame. For electronic types, no thermal units are needed. Verify the motor full-load current range and required auxiliary contacts (1NO/1NC) for your control circuit.
