EATON Potentiometer: 22 mm Panel Mounting Size, 4,700 ohm Max Resist Rating - Potentiometers with Dial Plates & Operators
EATONPotentiometers with Dial Plates & Operators

EATON Potentiometer: 22 mm Panel Mounting Size, 4,700 ohm Max Resist Rating

The EATON M22 Series Potentiometer (SKU 60JN52) is a 22 mm panel-mounting potentiometer with a 4,700 ohm maximum resistance rating. It features an oversized knob, a metallic (chrome) bezel, and includes a dial plate…

SKU 3G-OTH-34152

Brand
EATON
Item
Potentiometer: 22 mm Panel Mounting Size, 4,700 ohm Max Resist Rating
Category
Potentiometers with Dial Plates & Operators
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
M22M-R4K7-RH
Series
M22
Type
Metallic (Chrome) Bezel
Knob Style
Oversized
Bezel Style
Metallic (Chrome)
Max Resist Rating
4,700 ohm
Includes Dial Plate
Dial Plate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON M22 Series Potentiometer (SKU 60JN52) is a 22 mm panel-mounting potentiometer with a 4,700 ohm maximum resistance rating. It features an oversized knob, a metallic (chrome) bezel, and includes a dial plate. This device is designed for industrial control applications requiring precise resistance adjustment.

Frequently Asked Questions

What is the EATON M22M-R4K7-RH potentiometer used for?

The EATON M22M-R4K7-RH potentiometer is used in industrial control panels for precise resistance adjustment. It is commonly applied in motor speed controls, lighting dimmers, and process automation systems where a 22 mm panel-mounting component with a 4,700 ohm maximum resistance rating is required.

What are the specifications of the EATON M22M-R4K7-RH potentiometer?

The EATON M22M-R4K7-RH potentiometer has a 22 mm panel mounting size, a maximum resistance rating of 4,700 ohm, and includes a dial plate. It features an oversized knob and a metallic (chrome) bezel. It is part of the EATON M22 series with manufacturer part number M22M-R4K7-RH.

Where to buy the EATON M22M-R4K7-RH potentiometer worldwide?

You can source the EATON M22M-R4K7-RH potentiometer from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this EATON M22 series component.

How to install the EATON M22M-R4K7-RH potentiometer?

To install the EATON M22M-R4K7-RH potentiometer, mount it in a 22 mm panel cutout and secure the metallic (chrome) bezel. Connect the wiring to the appropriate terminals per the circuit diagram. Ensure the dial plate is aligned for accurate resistance adjustment. Follow standard industrial control installation practices.

Used in

Common applications for EATON
Industrial control panels — Eaton M22 flush push buttons for momentary machine start/stop commands
Motor control centers — Eaton NEMA reversing starters with electronic overloads for conveyor belt direction control
HVAC systems — Eaton definite purpose starters with thermal overloads for compressor and fan motor protection
Process automation — Eaton SL7 tower lights with IP66 bases for visual status indication in wet environments
Machine tool signaling — Eaton 10250T LED pilot lights with push-to-test for operator panel status lamps
Access control — Eaton M22 keyed selector switches for equipment mode selection in secured areas
