EATON NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4, 135 A - Enclosed Non-Reversing Starters with Electronic Overloads
EATON NEMAEnclosed Non-Reversing Starters with Electronic Overloads

EATON NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4, 135 A

The EATON NEMA Magnetic Motor Starter is an enclosed non-reversing starter with electronic overloads, featuring three poles, NEMA Size 4, and a 135 A rating. It operates with a 480V AC coil and includes a pilot…

SKU 3G-OTH-130918

Brand
EATON NEMA
Item
Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4, 135 A
Category
Enclosed Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON NEMA
Manufacturer Part Number
ECN0544CAA-R63/F
Type
NEMA Size 4, 135 A
Poles
3
AC Coil
480V
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON NEMA Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON NEMA Magnetic Motor Starter is an enclosed non-reversing starter with electronic overloads, featuring three poles, NEMA Size 4, and a 135 A rating. It operates with a 480V AC coil and includes a pilot light, along with 1NO/1NC auxiliary contacts. This starter is designed for three-phase motor control applications.

Frequently Asked Questions

What is the EATON NEMA Magnetic Motor Starter used for?

This enclosed non-reversing starter with electronic overloads controls three-phase motors in industrial applications. It is rated NEMA Size 4, 135 A, with a 480V AC coil, and includes a pilot light plus 1NO/1NC auxiliary contacts for monitoring and control.

What are the specifications of the EATON NEMA Magnetic Motor Starter ECN0544CAA-R63/F?

The EATON starter is NEMA Size 4, 135 A, with 3 poles, a 480V AC coil, and electronic overloads. It includes 1NO/1NC auxiliary contacts and a pilot light. The manufacturer part number is ECN0544CAA-R63/F.

Where to buy the EATON NEMA Magnetic Motor Starter worldwide?

3G Electric supplies the EATON NEMA Magnetic Motor Starter ECN0544CAA-R63/F to customers worldwide. We handle full logistics, customs clearance, and delivery, ensuring you receive the correct Eaton starter for your three-phase motor control needs.

How to select the correct EATON NEMA Magnetic Motor Starter for a motor?

Match the starter's NEMA Size and full-load current rating to your motor's nameplate. For this EATON Size 4, 135 A unit, verify your motor's FLA does not exceed 135 A and that the coil voltage matches your control circuit (480V AC). Consult a qualified electrician for proper sizing.

Used in

Common applications for EATON NEMA
HVAC systems — Eaton NEMA Size 1 starter (27 A) for controlling condenser fan motors in commercial air handlers.
Pumping stations — Eaton NEMA Size 2 starter (45 A) for starting and stopping irrigation pump motors with electronic overload protection.
Material handling — Eaton NEMA Size 0 starter (18 A) for conveyor belt motors in warehouse distribution centers.
Compressor control — Eaton NEMA Size 3 starter (90 A) for reciprocating air compressors requiring non-reversing motor starting.
Machine tools — Eaton NEMA Size 00 starter (9 A) for small lathe or drill press motors with 24V AC control circuits.
Water treatment — Eaton NEMA Size 2 starter (45 A) for aeration blower motors in municipal wastewater plants.

EATON NEMA Products

3G Electric supplies EATON NEMA enclosed non-reversing starters with electronic overloads. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
