EATON NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4, 135 A - Enclosed Non-Reversing Starters with Electronic Overloads
EATON NEMAEnclosed Non-Reversing Starters with Electronic Overloads

EATON NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4, 135 A

The EATON NEMA Magnetic Motor Starter is an enclosed non-reversing starter with electronic overloads, featuring three poles, NEMA Size 4, and a 135 A rating. It operates with a 24V AC coil and includes a pilot light…

SKU 3G-OTH-130902

Brand
EATON NEMA
Item
Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4, 135 A
Category
Enclosed Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON NEMA
Manufacturer Part Number
ECN0544TAA-R63/F
Type
NEMA Size 4, 135 A
Poles
3
AC Coil
24V
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON NEMA Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON NEMA Magnetic Motor Starter is an enclosed non-reversing starter with electronic overloads, featuring three poles, NEMA Size 4, and a 135 A rating. It operates with a 24V AC coil and includes a pilot light, along with 1NO/1NC auxiliary contacts. This unit is designed for global B2B industrial applications requiring reliable motor control.

Frequently Asked Questions

What is the EATON NEMA Magnetic Motor Starter used for?

This enclosed non-reversing starter with electronic overloads controls three-phase motors in industrial applications such as conveyors, pumps, and compressors. It provides reliable motor starting and protection across 14 industrial departments, with specialist support for combustion, pumps, and controls.

What are the specifications of the EATON NEMA Magnetic Motor Starter ECN0544TAA-R63/F?

The EATON NEMA Size 4 starter is rated 135 A with three poles and a 24V AC coil. It includes 1NO/1NC auxiliary contacts and a pilot light. The electronic overload is integral. This unit is designed for global B2B motor control applications.

Where to buy the EATON NEMA Magnetic Motor Starter ECN0544TAA-R63/F worldwide?

3G Electric supplies and delivers the EATON NEMA Magnetic Motor Starter worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to ensure your order reaches any international destination. Contact us for availability and lead time.

How to select the correct NEMA magnetic motor starter for a motor?

Match the NEMA size and ampere rating to the motor's full-load current and voltage. For this EATON Size 4 starter rated 135 A, verify the motor's FLA does not exceed the starter rating. Confirm coil voltage (24V AC) matches the control circuit. Consult a qualified engineer for proper selection.

Used in

Common applications for EATON NEMA
HVAC systems — Eaton NEMA Size 1 starter (27 A) for controlling condenser fan motors in commercial air handlers.
Pumping stations — Eaton NEMA Size 2 starter (45 A) for starting and stopping irrigation pump motors with electronic overload protection.
Material handling — Eaton NEMA Size 0 starter (18 A) for conveyor belt motors in warehouse distribution centers.
Compressor control — Eaton NEMA Size 3 starter (90 A) for reciprocating air compressors requiring non-reversing motor starting.
Machine tools — Eaton NEMA Size 00 starter (9 A) for small lathe or drill press motors with 24V AC control circuits.
Water treatment — Eaton NEMA Size 2 starter (45 A) for aeration blower motors in municipal wastewater plants.
