ELESA Hand Knob: Wing, Plastic, 200 mm Nominal Tether Lg, M10 Thread, 30 mm Thread Lg - Tethered Wing Knobs with Threaded Stud
ELESATethered Wing Knobs with Threaded Stud

ELESA Hand Knob: Wing, Plastic, 200 mm Nominal Tether Lg, M10 Thread, 30 mm Thread Lg

The ELESA Hand Knob: Wing is a tethered wing knob with a threaded stud, featuring an M10 thread and a 30 mm thread length. It includes a 200 mm nominal tether made of black POM-based technopolymer. This plastic…

SKU 3G-OTH-503386

Brand
ELESA
Item
Hand Knob: Wing, Plastic, 200 mm Nominal Tether Lg, M10 Thread, 30 mm Thread Lg
Category
Tethered Wing Knobs with Threaded Stud
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ELESA
Manufacturer Part Number
222763-C1
Type
Plastic, M10 Thread, Stud
Thread Lg
30 mm
Tether Color
Black
Tether Material
POM-Based Technopolymer
Nominal Tether Lg
200 mm
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ELESA Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ELESA Hand Knob: Wing is a tethered wing knob with a threaded stud, featuring an M10 thread and a 30 mm thread length. It includes a 200 mm nominal tether made of black POM-based technopolymer. This plastic component is identified by manufacturer part number 222763-C1.

Frequently Asked Questions

What is the ELESA Hand Knob: Wing used for?

The ELESA Hand Knob: Wing is a tethered wing knob used for quick manual clamping and adjustment in industrial machinery, assembly fixtures, and safety-critical applications where the knob must remain attached to prevent loss or contamination.

What are the specifications of the ELESA 222763-C1 tethered wing knob?

The ELESA 222763-C1 tethered wing knob has an M10 threaded stud with a 30 mm thread length, a 200 mm nominal tether made of black POM-based technopolymer, and a plastic body. It is designed for secure manual fastening in industrial settings.

Where to buy the ELESA 222763-C1 tethered wing knob worldwide?

3G Electric supplies the ELESA 222763-C1 tethered wing knob worldwide, handling full logistics and customs clearance. As a global industrial solutions provider, we source and deliver genuine ELESA components to support your maintenance and production needs.

How to install the ELESA tethered wing knob with threaded stud?

To install the ELESA tethered wing knob, thread the M10 stud into a matching tapped hole or nut until snug. Use the wing for hand tightening only; do not apply tools. Ensure the tether is secured to a fixed point to prevent loss during operation.
