EZO Miniature Ball Bearing: 686, Dbl Shield, 6 mm Bore, 13 mm OD, 5 mm Wd - High-Precision Radial Ball Bearings
EZOHigh-Precision Radial Ball Bearings

EZO Miniature Ball Bearing: 686, Dbl Shield, 6 mm Bore, 13 mm OD, 5 mm Wd

The EZO Miniature Ball Bearing 686 is a high-precision radial ball bearing with a metric system of measurement. It features a 6 mm bore, 13 mm outer diameter, and 5 mm width, with double shields and a stainless steel…

SKU 3G-OTH-104580

Brand
EZO
Item
Miniature Ball Bearing: 686, Dbl Shield, 6 mm Bore, 13 mm OD, 5 mm Wd
Category
High-Precision Radial Ball Bearings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EZO
Manufacturer Part Number
686HZZP6MC3SRL
Type
Dbl Shield, Stainless Steel Ring
Bore
6 mm
OD
13 mm
Wd
5 mm
System of Measurement
Metric
Bearing Industry Number
686
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EZO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EZO Miniature Ball Bearing 686 is a high-precision radial ball bearing with a metric system of measurement. It features a 6 mm bore, 13 mm outer diameter, and 5 mm width, with double shields and a stainless steel ring (MPN 686HZZP6MC3SRL). This bearing is designed for applications requiring compact, precision rolling elements.

Frequently Asked Questions

What is the EZO 686 miniature ball bearing used for?

The EZO 686 miniature ball bearing is used in compact, high-precision applications such as small motors, medical devices, robotics, and instrumentation. Its double shields and stainless steel ring provide protection against contaminants, making it suitable for clean environments requiring reliable, low-friction rotation.

What are the specifications of the EZO 686 bearing?

The EZO 686 bearing has a 6 mm bore, 13 mm outer diameter, and 5 mm width. It is a metric, double-shielded radial ball bearing with a stainless steel ring. The manufacturer part number is 686HZZP6MC3SRL, and the bearing industry number is 686.

Where to buy the EZO 686 miniature ball bearing worldwide?

You can source the EZO 686 miniature ball bearing from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to select the correct EZO miniature ball bearing for an application?

To select the correct EZO miniature ball bearing, match the bore, outer diameter, and width to your housing and shaft dimensions. Consider load type, speed, and environmental factors. The 686 model with double shields suits clean, low-contamination environments. For higher speeds or sealed options, consult the EZO catalog.

Used in

Common applications for EZO
Medical instruments — EZO stainless steel miniature ball bearings (e.g., 692XHZZP6MC3AF2) in dental handpieces and surgical tools
Precision encoders — EZO flanged bearings (e.g., F685HZZP6MC3SRL) for optical encoder shafts requiring axial location
Small electric motors — EZO radial ball bearings (e.g., 686HZZP6MC3SRL) in miniature DC motors and servo actuators
Instrumentation — EZO high-clearance bearings (e.g., SFR2-5 A3MC3AF2) in flow meters and pressure sensors
Robotics — EZO inch-series bearings (e.g., SR188ZZA3MC3SRL) in compact joint modules and end-effectors
Aerospace actuators — EZO corrosion-resistant bearings (e.g., SFR166ZZA3MC3AF2) in control surface linkages
