FAG BEARINGS Angular Contact Ball Bearing: 3206/5206, 2 Rows, 30°, Open, ABEC 3, Steel Cage - Double-Row Angular Contact Bearings
FAG BEARINGSDouble-Row Angular Contact Bearings

FAG BEARINGS Angular Contact Ball Bearing: 3206/5206, 2 Rows, 30°, Open, ABEC 3, Steel Cage

The FAG BEARINGS Angular Contact Ball Bearing, model 3206/5206 (MPN 3206-BD-XL-C3), is a double-row angular contact bearing with a 30° contact angle. It features an open design, ABEC 3 precision, a steel cage, and…

SKU 3G-OTH-104085

Brand
FAG BEARINGS
Item
Angular Contact Ball Bearing: 3206/5206, 2 Rows, 30°, Open, ABEC 3, Steel Cage
Category
Double-Row Angular Contact Bearings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

FAG BEARINGS
Manufacturer Part Number
3206-BD-XL-C3
Type
30°, Open, ABEC 3, Steel Cage, SUJ2
Rows
2
Bearing Type
Single Bearing
Contact Bearing Type
Angular Contact
Matched Bearing Type
Not Matched/Single Bearing
System of Measurement
Metric
Bearing Industry Number
3206/5206
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

FAG BEARINGS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The FAG BEARINGS Angular Contact Ball Bearing, model 3206/5206 (MPN 3206-BD-XL-C3), is a double-row angular contact bearing with a 30° contact angle. It features an open design, ABEC 3 precision, a steel cage, and SUJ2 material. This single bearing is metric and not matched.

Frequently Asked Questions

What is the FAG 3206-BD-XL-C3 angular contact ball bearing used for?

This double-row angular contact ball bearing handles combined radial and axial loads in industrial machinery such as pumps, compressors, and gearboxes. Its 30° contact angle and steel cage suit moderate-speed applications requiring rigidity and precision.

What are the specifications of the FAG 3206/5206 bearing?

The FAG 3206-BD-XL-C3 is a metric, single bearing with ABEC 3 precision, a steel cage, and SUJ2 material. It has a 30° contact angle, open design, and is not matched. The bearing industry number is 3206/5206.

Where to buy FAG 3206-BD-XL-C3 bearings worldwide?

3G Electric supplies the FAG 3206-BD-XL-C3 angular contact ball bearing worldwide. As a global industrial distributor since 1990, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to select the correct FAG angular contact bearing for an application?

Select based on load type, speed, and mounting arrangement. For combined radial-axial loads, a double-row bearing like the 3206-BD-XL-C3 with a 30° contact angle is suitable. Verify shaft and housing fits per ISO tolerances and ensure lubrication matches operating conditions.

Used in

Common applications for FAG BEARINGS
Electric motor repair — FAG double-row angular contact bearings (3306-BD-XL) for rotor support in medium-voltage motors
Machine tool spindles — FAG high-precision angular contact bearings (7210-B-XL-TVP-UA) for tandem duplex mounting in grinding spindles
Industrial pump assemblies — FAG self-aligning ball bearings (2203-2RS-TVH) for accommodating shaft misalignment in centrifugal pumps
Gearbox maintenance — FAG cylindrical roller bearings (NU207-E-XL-M1-C3) for high radial load and axial displacement in helical gear units
Compressor rebuilds — FAG angular contact bearings (7317-B-XL-TVP-UA) for thrust load handling in reciprocating compressors
Conveyor systems — FAG double-row angular contact bearings (3207-BD-XL-2Z) for sealed operation in belt conveyor idler rolls
