FBRBurners & Combustion

FBR variant_2

FBR GAS/2 is a two-stage gas burner for industrial heating applications, delivering thermal power up to 1647 Mcal/h with a maximum combustion air temperature of 60°C. The unit operates on 3~400V, 1/N~230V-50Hz supply…

SKU 3G-FBR-00624

Also listed as: 05703731 · 057037 31 · 057037-31

Brand

FBR

Item

variant_2

Local availability & support — Singapore

Local office: 20 Woodlands Link #09-05, Singapore 738733
Phone: +65 8878 8355
Delivery: Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
Payment: Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
Ships to: Singapore

Technical Specifications

FBR

Weight

44 kg

stage

2 stages sliding or modulating

fuel type

Gas

nozzle mm

280

fan motor w

4

power kw max

1915

ip protection

IP 40

noisiness dba

84.3-86.6

gas consumption

30.2/89.5-192

electrical supply

3

power supply info

3~400V, 1/N~230V-50Hz

current absorption a

7.45

thermal power mcal h

258/765-1647

nominal electric power w

4.2

max combustion air temp c

60

Datasheet Content

BURNERS FOR GAS
                                                   SPECIFIC FOR INDUSTRIAL KITCHENS

                                               Burners for gas specific for industrial kitchens with power command and on/off switch.
                                               Complete of flange and gasket.

      TECHNICAL DATA
MODEL                                                                    GAS 1/C                                GAS 2/C
Thermal power                                  Mcal/h                     10-40                                  15-60
Thermal power                                  kW                     11.6-46.4                                 17.4-69.6
G20 (NATURAL GAS) Delivery                     Nm3/h                     1.17-4.7                                1.75-7
G31 (L.P.G.) Delivery                          Nm3/h                     0.45-1.8                               0.67-2.7
Nominal pressure G20 (NATURAL GAS)             mbar                        20                                      20
Nominal pressure G25                           mbar                        25                                      25
Nominal pressure G30                           mbar                        29                                      29
Nominal pressure G31 (L.P.G.)                  mbar                        37                                      37
Maximum pressure                               mbar                        40                                      40
Motor power                                    W                           75                                     110
Maximum absorbed power                         W                           215                                    250
Electrical supply                                                                   1/Nac230V-50Hz
Level of electrical protection                                                            IP40
Safety time of control box                                                              = < 3 sec.

      OVERALL DIMENSIONS (mm)

  MODEL          A      B        C   D    E        F    G     H      I       L      M      N     O    P    TC     TL      R2      Ø
  GAS 1/C       321   166    184     90   43    310     210   75   130     160      130   100    30   M8   85     145     128   G 1/2”
  GAS 2/C       321   166    184     90   43    310     210   75   130     160      130   100    30   M8   85     145     128   G 1/2”

F.B.R. BRUCIATORI - MADE IN ITALY - COMPANY QUALITY CERTIFIED ISO 9001

Technical Documents

No technical documents available for this product.

Request documentation →

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

FBR Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

What is the FBR GAS/2 CE-CT D1"1/2-S gas burner used for?

The FBR GAS/2 CE-CT D1"1/2-S is a two-stage gas burner designed for industrial heating applications, including industrial kitchens. It delivers thermal power up to 1647 Mcal/h and supports modulating or sliding stage control for precise fuel management.

What are the specifications of the FBR GAS/2 CE-CT D1"1/2-S?

The FBR GAS/2 CE-CT D1"1/2-S operates on 3~400V, 1/N~230V-50Hz supply, with a maximum combustion air temperature of 60°C. It has a fan motor power of 4 W, IP 40 protection, and a weight of 44 kg. The burner uses gas fuel and has a nozzle size of 280 mm.

Where to buy the FBR GAS/2 CE-CT D1"1/2-S in Singapore?

You can source the FBR GAS/2 CE-CT D1"1/2-S through 3G Electric in Singapore. We handle logistics, customs clearance, and delivery to your facility. Contact us for availability and lead time on this industrial gas burner.

How to install the FBR GAS/2 CE-CT D1"1/2-S gas burner?

Installation of the FBR GAS/2 CE-CT D1"1/2-S should follow the manufacturer's manual and local gas safety codes. Ensure proper flange and gasket sealing, correct electrical supply (3~400V, 1/N~230V-50Hz), and adequate combustion air temperature below 60°C. Professional commissioning is recommended.

Used in

Common applications for FBR

Hospitality and commercial HVAC — cast-iron boiler plants in hotels and shopping complexes

Pharmaceutical and biotech process heat — gas-fired burners with ATEX gas trains for classified-zone requirements

Medical-waste and bio-hazard incineration — FGP progressive dual-fuel systems

Food and beverage steam boilers — single-stage G-series for continuous-duty cycles

Marine and offshore platforms — IP54-rated X-series for high-humidity marine operations
