GE Molded Case Circuit Breaker: 25 A Amps, 25kA at 277/480V AC, Fixed, Lug - TEY-Frame GE Molded Case Circuit Breakers
GETEY-Frame GE Molded Case Circuit Breakers

GE Molded Case Circuit Breaker: 25 A Amps, 25kA at 277/480V AC, Fixed, Lug

The GE TEY-Frame Molded Case Circuit Breaker (SKU 32HZ25, MPN TEYD3025B) is a 25 A rated circuit breaker from the TEY series. It features a maximum AIR rating of 25kA at 277/480V AC, a fixed instantaneous trip, and…

SKU 3G-OTH-23386

Brand
GE
Item
Molded Case Circuit Breaker: 25 A Amps, 25kA at 277/480V AC, Fixed, Lug
Category
TEY-Frame GE Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GE
Manufacturer Part Number
TEYD3025B
Series
TEY
Type
25kA at 277/480V AC, Fixed, Lug, ABC, Std
Max. AIR Rating
25kA at 277/480V AC
Phase Connection
ABC
Instantaneous Trip
Fixed
Terminal Connection
Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GE Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GE TEY-Frame Molded Case Circuit Breaker (SKU 32HZ25, MPN TEYD3025B) is a 25 A rated circuit breaker from the TEY series. It features a maximum AIR rating of 25kA at 277/480V AC, a fixed instantaneous trip, and lug terminal connections for ABC phase connection.

Frequently Asked Questions

What is the GE TEYD3025B molded case circuit breaker used for?

The GE TEYD3025B is a 25 A molded case circuit breaker used for overcurrent protection in industrial and commercial electrical distribution systems. It is suitable for branch circuit protection in panelboards and switchboards, with a 25kA interrupting rating at 277/480V AC for ABC phase connections.

What are the specifications of the GE TEYD3025B circuit breaker?

The GE TEYD3025B is a TEY-frame molded case circuit breaker rated 25 A with a maximum AIR rating of 25kA at 277/480V AC. It features a fixed instantaneous trip, lug terminal connections, and ABC phase connection. The manufacturer part number is TEYD3025B.

Where to buy the GE TEYD3025B circuit breaker worldwide?

3G Electric supplies the GE TEYD3025B circuit breaker worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this TEY-series molded case circuit breaker.

How to select the correct GE TEY series circuit breaker for my application?

To select the correct GE TEY series circuit breaker, verify the continuous current rating (e.g., 25 A), interrupting rating (25kA at 277/480V AC), and phase connection (ABC). Ensure the fixed instantaneous trip and lug terminals match your panelboard requirements. Consult a licensed electrician for proper coordination.
