GE Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4, 135 A - Non-Reversing Starters with Thermal Overloads
GENon-Reversing Starters with Thermal Overloads

GE Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4, 135 A

The GE Magnetic Motor Starter: Non-Reversing (SKU 3HXZ4, MPN CR306F002) is a non-reversing starter with thermal overloads, featuring three poles, NEMA Size 4, and a 135 A rating. It operates on a 120V AC coil voltage…

SKU 3G-OTH-41877

Brand
GE
Item
Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4, 135 A
Category
Non-Reversing Starters with Thermal Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GE
Manufacturer Part Number
CR306F002
Type
NEMA Size 4, 135 A
Phase
Three
Poles
3
AC Coil
120V
Coil Voltage
120V AC
Signaling Features
Pilot Light
Thermal Units Required
3 Melting Alloy Units (Not Included)
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GE Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GE Magnetic Motor Starter: Non-Reversing (SKU 3HXZ4, MPN CR306F002) is a non-reversing starter with thermal overloads, featuring three poles, NEMA Size 4, and a 135 A rating. It operates on a 120V AC coil voltage for three-phase applications and includes a pilot light for signaling. This unit requires three melting alloy thermal units (not included) for overload protection.

Frequently Asked Questions

What is a GE magnetic motor starter used for?

A GE magnetic motor starter, such as the CR306F002, is used to start and stop three-phase motors while providing overload protection. It is common in industrial applications like conveyors, pumps, and compressors, where reliable motor control and signaling via a pilot light are required.

What are the specifications of the GE CR306F002 magnetic motor starter?

The GE CR306F002 is a non-reversing, three-pole starter with NEMA Size 4, rated 135 A. It operates on a 120V AC coil voltage for three-phase applications and includes a pilot light. It requires three melting alloy thermal units (not included) for overload protection.

Where to buy a GE CR306F002 magnetic motor starter worldwide?

3G Electric supplies the GE CR306F002 magnetic motor starter worldwide. As a global industrial solutions provider, we handle logistics, customs, and delivery to your location. Contact us for availability and to place an order for this NEMA Size 4, 135 A starter.

How to select thermal units for a GE magnetic motor starter?

To select thermal units for a GE CR306F002 starter, match the melting alloy heater to the motor's full-load current rating. Consult the motor nameplate and GE's heater selection table. Three units are required for three-phase protection. Ensure the heater size does not exceed the starter's 135 A rating.
