GE Miniature Circuit Breaker: THHQC, 20 A, 120/240V AC, Single Phase, 22kA at 120/240V AC - THQC & THHQC Series, Unit-Mount GE Miniature Circuit Breakers
GETHQC & THHQC Series, Unit-Mount GE Miniature Circuit Breakers

GE Miniature Circuit Breaker: THHQC, 20 A, 120/240V AC, Single Phase, 22kA at 120/240V AC

The GE THHQC is a unit-mount miniature circuit breaker from the THQC & THHQC Series, designed for use with GE Panelboards. This single-phase model is rated at 20 A and 120/240V AC, with a maximum AIR rating of 22kA…

SKU 3G-OTH-22003

Brand
GE
Item
Miniature Circuit Breaker: THHQC, 20 A, 120/240V AC, Single Phase, 22kA at 120/240V AC
Category
THQC & THHQC Series, Unit-Mount GE Miniature Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GE
Manufacturer Part Number
THHQC1120WL
Type
20 A, Single Phase, 22kA at 120/240V AC, Std
AC
120/240V
Amps
20 A
Phase
Single
For Use With
GE Panelboards
Max. AIR Rating
22kA at 120/240V AC
AC Voltage Rating
120/240V AC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GE Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GE THHQC is a unit-mount miniature circuit breaker from the THQC & THHQC Series, designed for use with GE Panelboards. This single-phase model is rated at 20 A and 120/240V AC, with a maximum AIR rating of 22kA at 120/240V AC.
