GE Molded Case Circuit Breaker: 35 A Amps, 18kA at 120/240/277/480V AC, Fixed - TED-, TEHD-Frame GE Molded Case Circuit Breakers
GETED-, TEHD-Frame GE Molded Case Circuit Breakers

GE Molded Case Circuit Breaker: 35 A Amps, 18kA at 120/240/277/480V AC, Fixed

The GE TED124035WL is a TED-series molded case circuit breaker rated for 35 amps with a maximum AIR rating of 18kA at 120/240/277/480V AC. It features a fixed instantaneous trip and line/load lug terminal…

SKU 3G-OTH-21529

Brand
GE
Item
Molded Case Circuit Breaker: 35 A Amps, 18kA at 120/240/277/480V AC, Fixed
Category
TED-, TEHD-Frame GE Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GE
Manufacturer Part Number
TED124035WL
Series
TED
Type
18kA at 120/240/277/480V AC, Fixed, Line/Load Lug
Max. AIR Rating
18kA at 120/240/277/480V AC
Instantaneous Trip
Fixed
Terminal Connection
Line/Load Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GE Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GE TED124035WL is a TED-series molded case circuit breaker rated for 35 amps with a maximum AIR rating of 18kA at 120/240/277/480V AC. It features a fixed instantaneous trip and line/load lug terminal connections. This unit is part of the TED- and TEHD-frame GE molded case circuit breaker product type.

Frequently Asked Questions

What is the GE TED124035WL molded case circuit breaker used for?

The GE TED124035WL is a 35-amp molded case circuit breaker used for overcurrent protection in industrial and commercial electrical distribution panels. It is suitable for branch-circuit protection in lighting, motor, and general power applications where a fixed instantaneous trip and line/load lug connections are required.

What are the specifications of the GE TED124035WL circuit breaker?

The GE TED124035WL is a TED-series molded case circuit breaker rated at 35 amps with a maximum AIR rating of 18kA at 120/240/277/480V AC. It features a fixed instantaneous trip and line/load lug terminal connections. The part number is TED124035WL.

Where to buy the GE TED124035WL circuit breaker worldwide?

3G Electric supplies the GE TED124035WL molded case circuit breaker to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us for pricing and lead time on this GE breaker.

How to select the correct GE molded case circuit breaker for my application?

To select the correct GE molded case circuit breaker, verify the continuous current rating (35 amps for the TED124035WL), the maximum available fault current (18kA at 120/240/277/480V AC), and the required trip type (fixed instantaneous). Ensure terminal connections match your panel's lug configuration. Consult a licensed electrician for code compliance.
