GE Molded Case Circuit Breaker: 90 A Amps, 18kA at 120/240/277/480V AC, Fixed - TED-, TEHD-Frame GE Molded Case Circuit Breakers
GETED-, TEHD-Frame GE Molded Case Circuit Breakers

GE Molded Case Circuit Breaker: 90 A Amps, 18kA at 120/240/277/480V AC, Fixed

The GE Molded Case Circuit Breaker, model TED124090WL, is a 90 A amp TED- and TEHD-frame molded case circuit breaker from the TED series. It features a maximum AIR rating of 18kA at 120/240/277/480V AC, a fixed…

SKU 3G-OTH-21293

Brand
GE
Item
Molded Case Circuit Breaker: 90 A Amps, 18kA at 120/240/277/480V AC, Fixed
Category
TED-, TEHD-Frame GE Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GE
Manufacturer Part Number
TED124090WL
Series
TED
Type
18kA at 120/240/277/480V AC, Fixed, Line/Load Lug
Max. AIR Rating
18kA at 120/240/277/480V AC
Instantaneous Trip
Fixed
Terminal Connection
Line/Load Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GE Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GE Molded Case Circuit Breaker, model TED124090WL, is a 90 A amp TED- and TEHD-frame molded case circuit breaker from the TED series. It features a maximum AIR rating of 18kA at 120/240/277/480V AC, a fixed instantaneous trip, and line/load lug terminal connections.

Frequently Asked Questions

What is the GE TED124090WL molded case circuit breaker used for?

The GE TED124090WL is a 90 A molded case circuit breaker used for overcurrent protection in commercial and industrial electrical distribution panels. It is suitable for branch-circuit and feeder protection in applications requiring a fixed instantaneous trip and line/load lug connections.

What are the specifications of the GE TED124090WL circuit breaker?

The GE TED124090WL is a 90 A, TED-series molded case circuit breaker with a maximum AIR rating of 18kA at 120/240/277/480V AC. It features a fixed instantaneous trip and line/load lug terminal connections. The manufacturer part number is TED124090WL.

Where to buy the GE TED124090WL circuit breaker worldwide?

3G Electric supplies the GE TED124090WL molded case circuit breaker worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to select the right GE molded case circuit breaker for my application?

To select the right GE molded case circuit breaker, verify the continuous current rating (e.g., 90 A), the maximum AIR rating (e.g., 18kA at 120/240/277/480V AC), and the trip type (fixed instantaneous). Ensure terminal connections (line/load lug) match your panel. Consult a licensed electrician for code compliance.
