GE Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 5, 270 A - Enclosed Non-Reversing Starters with Thermal Overloads
GEEnclosed Non-Reversing Starters with Thermal Overloads

GE Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 5, 270 A

The GE Magnetic Motor Starter is an enclosed non-reversing starter with thermal overloads, featuring three poles, NEMA Size 5, and a 270 A rating. It operates with a 480V AC coil voltage for three-phase applications…

SKU 3G-OTH-42160

Brand
GE
Item
Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 5, 270 A
Category
Enclosed Non-Reversing Starters with Thermal Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GE
Manufacturer Part Number
CR306G104
Type
NEMA Size 5, 270 A
Phase
Three
Poles
3
AC Coil
480V
Coil Voltage
480V AC
Signaling Features
Pilot Light
Thermal Units Required
3 Melting Alloy Units (Not Included)
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GE Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GE Magnetic Motor Starter is an enclosed non-reversing starter with thermal overloads, featuring three poles, NEMA Size 5, and a 270 A rating. It operates with a 480V AC coil voltage for three-phase applications and includes a pilot light for signaling. Three melting alloy thermal units are required but not included.

Frequently Asked Questions

What is a GE magnetic motor starter used for?

A GE magnetic motor starter controls and protects three-phase motors by switching power on/off and providing overload protection. This NEMA Size 5, 270 A enclosed non-reversing starter with a 480V AC coil is used in industrial applications like pumps, conveyors, and compressors across 14 departments.

What are the specifications of the GE CR306G104 motor starter?

The GE CR306G104 is a NEMA Size 5, 270 A, three-pole, non-reversing magnetic motor starter with a 480V AC coil voltage. It includes a pilot light for signaling and requires three melting alloy thermal units (not included). It is designed for three-phase applications.

Where to buy a GE CR306G104 motor starter worldwide?

3G Electric supplies the GE CR306G104 magnetic motor starter worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this NEMA Size 5, 270 A, 480V AC coil starter.

How to select thermal units for a GE NEMA Size 5 starter?

Select melting alloy thermal units based on the motor's full-load current rating. For a GE NEMA Size 5 starter like the CR306G104, use the motor nameplate amps to choose three units from the manufacturer's selection table. Install them in the overload relay to protect against sustained overcurrent.
