GENTEQ Direct Drive Blower Motor: Evergreen CM, 48 Frame Size, Belly Band, ECM - Evergreen® Series EC Motors
GENTEQEvergreen® Series EC Motors

GENTEQ Direct Drive Blower Motor: Evergreen CM, 48 Frame Size, Belly Band, ECM

The GENTEQ Direct Drive Blower Motor: Evergreen® CM is an Evergreen® Series EC motor with a 48 frame size and Open Air Over (OAO) enclosure. It is a constant-torque ECM motor rated at 1/2 hp (370 W), 1,075 RPM, 2.01…

SKU 3G-OTH-54394

Brand
GENTEQ
Item
Direct Drive Blower Motor: Evergreen CM, 48 Frame Size, Belly Band, ECM
Category
Evergreen® Series EC Motors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GENTEQ
Manufacturer Part Number
6405
Type
Belly Band, ECM, Open Air Over
Features
Multi-Speed (5 Taps @ 24vac)
Includes
Voltage Plugs
Frame Size
48
ECM Motor Type
Constant Torque
Motor Enclosure
OAO
Rated Horsepower
1/2 hp
Horsepower/Wattage
1/2 hp370 W
External Control Type
PWM Controller
Nameplate RPM @ 60 Hz
1,075 RPM
Full Load Amps @ 60 Hz
2.01 A
Includes User Interface
No
Nameplate Voltage @ 60 Hz
460V AC
External Controller Compatible
Yes
Compatible with External Controller
External Control Compatible
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GENTEQ Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GENTEQ Direct Drive Blower Motor: Evergreen® CM is an Evergreen® Series EC motor with a 48 frame size and Open Air Over (OAO) enclosure. It is a constant-torque ECM motor rated at 1/2 hp (370 W), 1,075 RPM, 2.01 A full load amps at 60 Hz, and 460V AC. This multi-speed motor offers 5 taps at 24 VAC and is compatible with an external PWM controller, including voltage plugs.

Frequently Asked Questions

What is the GENTEQ Evergreen CM blower motor used for?

The GENTEQ Evergreen CM direct drive blower motor is used in HVAC systems for residential and light commercial air handlers and furnaces. It provides constant-torque ECM performance for improved energy efficiency and quiet operation, replacing older PSC motors in belt-drive or direct-drive blower applications.

What are the specifications of the GENTEQ 6405 motor?

The GENTEQ 6405 is a 48-frame, OAO-enclosed ECM motor rated 1/2 hp (370 W), 1,075 RPM, 2.01 A full load at 460V AC, 60 Hz. It is a constant-torque motor with 5 speed taps at 24 VAC, compatible with an external PWM controller, and includes voltage plugs.

Where to buy the GENTEQ Evergreen CM motor worldwide?

3G Electric supplies the GENTEQ Evergreen CM motor (MPN 6405) to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this ECM blower motor.

How to install a GENTEQ Evergreen CM constant-torque motor?

Installation requires matching the 48-frame belly-band mounting to the blower housing, wiring the 5 speed taps at 24 VAC to the appropriate thermostat or controller, and connecting the external PWM controller if used. Always follow the manufacturer's wiring diagram and lockout/tagout procedures before servicing.

Used in

Common applications for GENTEQ
HVAC air-handling units — GENTEQ Evergreen IM constant-torque ECM for variable-speed blower replacement
Commercial furnace systems — GENTEQ Evergreen CM multi-speed motor for multi-zone airflow control
Rooftop unit retrofits — GENTEQ Evergreen EM with PWM auto-recognition for direct-drive fan upgrades
VFD control panel integration — GENTEQ 5K010 user interface for monitoring and parameter adjustment
Motor mounting in HVAC equipment — GENTEQ 5K005 bolt-circle bracket for securing Evergreen motors to existing frames

GENTEQ Products

3G Electric supplies GENTEQ evergreen® series ec motors. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
