GHIBSON Butterfly Valve: 3 in Pipe Size, Concentric, 250 psi Max. Pressure (CWP) - Ductile Iron General-Service Butterfly Valves
GHIBSONDuctile Iron General-Service Butterfly Valves

GHIBSON Butterfly Valve: 3 in Pipe Size, Concentric, 250 psi Max. Pressure (CWP)

The GHIBSON Butterfly Valve (MPN 540S-3) is a 3-inch ductile iron general-service butterfly valve with a wafer-style body and a stainless steel disc. It features a lever handle and is rated for a maximum pressure of…

SKU 3G-OTH-444696

Brand
GHIBSON
Item
Butterfly Valve: 3 in Pipe Size, Concentric, 250 psi Max. Pressure
Category
Ductile Iron General-Service Butterfly Valves
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GHIBSON
Manufacturer Part Number
540S-3
Type
Concentric, Wafer, Buna-N
Handle Type
Lever
Disc Material
Stainless Steel
Max. Pressure (CWP)
250 psi
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GHIBSON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GHIBSON Butterfly Valve (MPN 540S-3) is a 3-inch ductile iron general-service butterfly valve with a wafer-style body and a stainless steel disc. It features a lever handle and is rated for a maximum pressure of 250 psi (CWP) with a Buna-N seat. This concentric valve is designed for on/off or throttling service in industrial piping systems.

Frequently Asked Questions

What is the GHIBSON 540S-3 butterfly valve used for?

The GHIBSON 540S-3 butterfly valve is used for on/off or throttling service in industrial piping systems. Its 3-inch wafer-style body and Buna-N seat make it suitable for general-service applications such as water, air, and non-aggressive fluids at pressures up to 250 psi.

What are the specifications of the GHIBSON 540S-3 butterfly valve?

The GHIBSON 540S-3 is a 3-inch concentric butterfly valve with a ductile iron body, stainless steel disc, and Buna-N seat. It has a lever handle and a maximum pressure rating of 250 psi (CWP). The wafer-style design allows easy installation between flanges.

Where to buy the GHIBSON 540S-3 butterfly valve worldwide?

3G Electric supplies the GHIBSON 540S-3 butterfly valve worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time.

How to install a GHIBSON wafer-style butterfly valve?

Center the GHIBSON 540S-3 valve between pipe flanges, ensuring the disc is partially open to avoid seat damage. Insert bolts through both flanges and the valve body, then tighten nuts evenly in a cross pattern to the torque specified by the gasket manufacturer. Do not overtighten.
