GMN Super Precison Angular contact Bearing: KH 6003, Duplex, 17°, Open, ABEC P4 - High-Precision Angular Contact Bearings
GMNHigh-Precision Angular Contact Bearings

GMN Super Precison Angular contact Bearing: KH 6003, Duplex, 17°, Open, ABEC P4

The GMN KH 6003 is a metric, high-precision angular contact bearing, classified as a matched duplex bearing with an ABEC P4 rating. It features a 17° contact angle, an open design, and a phenolic cage, supplied as a…

SKU 3G-OTH-99118

Brand
GMN
Item
Super Precison Angular contact Bearing: KH 6003, Duplex, 17°, Open, ABEC P4
Category
High-Precision Angular Contact Bearings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GMN
Manufacturer Part Number
HYKH6003 CTA P4+ DUL
Type
Duplex, 17°, Open, ABEC P4, Phenolic Cage
PR
1
ABEC Rating
P4
Bearing Type
Matched Bearing
Contact Bearing Type
Angular Contact
Matched Bearing Type
Duplex
System of Measurement
Metric
Bearing Industry Number
KH 6003
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GMN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GMN KH 6003 is a metric, high-precision angular contact bearing, classified as a matched duplex bearing with an ABEC P4 rating. It features a 17° contact angle, an open design, and a phenolic cage, supplied as a single pair (1 PR). This bearing is identified by manufacturer part number HYKH6003 CTA P4+ DUL.

Frequently Asked Questions

What is the GMN KH 6003 duplex angular contact bearing used for?

The GMN KH 6003 is a high-precision angular contact bearing used in machine tool spindles, robotics, and other applications requiring accurate shaft positioning and high-speed operation. Its duplex matched pair and P4 tolerance class provide minimal runout and consistent preload for demanding industrial machinery.

What are the specifications of the GMN KH 6003 bearing?

The GMN KH 6003 is a metric, matched duplex angular contact bearing with a 17° contact angle, open design, and phenolic cage. It carries an ABEC P4 (ISO P4) precision rating and is supplied as a single pair (1 PR). The manufacturer part number is HYKH6003 CTA P4+ DUL.

Where to buy the GMN KH 6003 bearing worldwide?

3G Electric supplies the GMN KH 6003 duplex angular contact bearing to customers worldwide. We handle full logistics, customs clearance, and delivery to your facility. Contact our team for a quote and lead time on this precision bearing.

How to select a duplex angular contact bearing like the GMN KH 6003?

Select a duplex bearing by matching the contact angle (17° for axial load capacity), precision class (P4 for high accuracy), and cage material (phenolic for high-speed stability). Ensure the pair is factory-matched for preload and runout. The GMN KH 6003 is a proven choice for spindle applications.

Used in

Common applications for GMN
Machine tool spindles — GMN KH series angular contact bearings (e.g., KH 6002) for high-speed, high-precision rotation
Robotics — GMN S series duplex bearings (e.g., S 61806) for joint articulation requiring axial rigidity
Printing presses — GMN FP series sprag clutches (e.g., FP 463-M) for overrunning and indexing in web feed systems
Industrial drives — GMN FPD series clutches (e.g., FPD 432-Z) for backstopping in conveyor and elevator applications
Automated assembly equipment — GMN KH 6001 bearings for positioning stages with low runout requirements
Packaging machinery — GMN matched duplex bearings (e.g., KH 6005) for high-speed rotary cutters and sealers

GMN Products

3G Electric supplies GMN high-precision angular contact bearings. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
