GRACO Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC - FDA-Compliant EODD Pumps
GRACOFDA-Compliant EODD Pumps

GRACO Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC

The GRACO Electric Diaphragm Pump (SKU 411VK6, MPN HE80-1500) is an FDA-compliant EODD pump with a stainless steel body, three-phase 380-480V AC operation, and a 1 1/2 in connection. It features a 316 SS seat, SS…

SKU 3G-OTH-91281

Brand
GRACO
Item
Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC
Category
FDA-Compliant EODD Pumps
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GRACO
Manufacturer Part Number
HE80-1500
Type
Three Phase, 1 1/2 in, SS Valve
AC
380-480V
Seat Material
316 SS
Nameplate Voltage
380-480V AC
Surface Roughness
32 Ra
Diaphragm Material
PTFE with EPDM Backing
Check Valve Material
SS
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GRACO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GRACO Electric Diaphragm Pump (SKU 411VK6, MPN HE80-1500) is an FDA-compliant EODD pump with a stainless steel body, three-phase 380-480V AC operation, and a 1 1/2 in connection. It features a 316 SS seat, SS check valves, and a PTFE diaphragm with EPDM backing, with a surface roughness of 32 Ra.

Frequently Asked Questions

What is the GRACO Electric Diaphragm Pump used for?

The GRACO Electric Diaphragm Pump (HE80-1500) is used for transferring fluids in sanitary and industrial applications requiring FDA compliance. Its stainless steel body and 32 Ra surface finish make it suitable for food, beverage, pharmaceutical, and chemical processing where cleanliness and corrosion resistance are critical.

What are the specifications of the GRACO Electric Diaphragm Pump?

The GRACO Electric Diaphragm Pump (MPN HE80-1500) operates on three-phase 380-480V AC power. It has a 1 1/2 in connection, a 316 SS seat, SS check valves, and a PTFE diaphragm with EPDM backing. Surface roughness is 32 Ra, and the body is stainless steel.

Where to buy the GRACO Electric Diaphragm Pump worldwide?

You can source the GRACO Electric Diaphragm Pump (HE80-1500) through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to select the right GRACO Electric Diaphragm Pump for your application?

Select the GRACO Electric Diaphragm Pump based on fluid compatibility, required flow rate, and power supply. For FDA-compliant transfer of aggressive fluids, the stainless steel body and PTFE diaphragm with EPDM backing offer chemical resistance. Ensure your facility provides three-phase 380-480V AC power.

Used in

Common applications for GRACO
Food and beverage processing — Graco FDA-compliant electric diaphragm pumps (e.g., HE120-1200) for sanitary fluid transfer
Pharmaceutical manufacturing — Graco USP Class VI-compliant AODD pumps (e.g., SP4F.0006) for sterile liquid handling
Chemical processing — Graco aluminum or stainless steel diaphragm pumps (e.g., TE120-1100) for corrosive fluid transfer
Automotive lubrication — Graco grease pump control replacement kits (e.g., 18F169) for maintenance of lubrication systems
Paint and coating application — Graco discharge spouts (e.g., 255858) for precise fluid dispensing in finishing lines
Water and wastewater treatment — Graco electric diaphragm pumps (e.g., HE120-1503) for sludge and chemical dosing
