GRACO Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC - FDA-Compliant EODD Pumps
GRACOFDA-Compliant EODD Pumps

GRACO Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC

The GRACO Electric Diaphragm Pump with Stainless Steel Body is an FDA-compliant EODD pump (SKU 411VN1, MPN HE120-1509) featuring a 3-inch port size, 18 ft max head, and three-phase 380-480V AC nameplate voltage. It…

SKU 3G-OTH-89051

Brand
GRACO
Item
Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC
Category
FDA-Compliant EODD Pumps
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GRACO
Manufacturer Part Number
HE120-1509
Type
Three Phase, 3 in
AC
380-480V
Max. Head
18 ft
Seat Material
316 SS
Nameplate Voltage
380-480V AC
Surface Roughness
32 Ra
Diaphragm Material
PTFE with Santoprene Backing
Check Valve Material
SS
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GRACO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GRACO Electric Diaphragm Pump with Stainless Steel Body is an FDA-compliant EODD pump (SKU 411VN1, MPN HE120-1509) featuring a 3-inch port size, 18 ft max head, and three-phase 380-480V AC nameplate voltage. It is constructed with a 316 SS seat material, SS check valve material, and a diaphragm material of PTFE with Santoprene backing, with a surface roughness of 32 Ra.

Frequently Asked Questions

What is the GRACO Electric Diaphragm Pump HE120-1509 used for?

This FDA-compliant EODD pump is designed for sanitary transfer of fluids in food, dairy, and pharmaceutical processing. Its 316 SS seat, PTFE diaphragm, and 32 Ra surface finish meet hygiene standards. GRACO pumps are trusted for reliable, contamination-free handling of viscous or shear-sensitive materials.

What are the specifications of the GRACO HE120-1509 pump?

The GRACO HE120-1509 is a three-phase electric diaphragm pump with a 3-inch port, 18 ft max head, and 380-480V AC nameplate voltage. It features a 316 SS seat, SS check valve, PTFE diaphragm with Santoprene backing, and 32 Ra surface roughness. The stainless steel body ensures corrosion resistance.

Where to buy the GRACO HE120-1509 pump worldwide?

3G Electric supplies the GRACO HE120-1509 pump to customers worldwide. We handle full logistics, customs clearance, and delivery to your facility. As a global industrial solutions provider, we source genuine GRACO equipment and support your procurement with technical expertise across 14 departments.

How to select the right GRACO electric diaphragm pump for my application?

Match the pump's port size, max head, and voltage to your system. For FDA applications, verify materials like 316 SS and PTFE meet your fluid compatibility and cleanliness requirements. Consult 3G Electric for guidance on flow rate, pressure, and diaphragm life to ensure optimal performance.
