GRACO Electric Diaphragm Pump: Aluminum Body, 2 in Fluid Connection Size - Aluminum Housing EODD Pumps
GRACOAluminum Housing EODD Pumps

GRACO Electric Diaphragm Pump: Aluminum Body, 2 in Fluid Connection Size

The GRACO Electric Diaphragm Pump with Aluminum Body is an aluminum housing EODD pump featuring a 2-inch NPT fluid connection. It operates with a nameplate voltage of 380-480V AC and includes 303 SS seat material…

SKU 3G-OTH-87564

Brand
GRACO
Item
Electric Diaphragm Pump: Aluminum Body, 2 in Fluid Connection Size
Category
Aluminum Housing EODD Pumps
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GRACO
Manufacturer Part Number
TE120-1114
Type
NPT Connection
Seat Material
303 SS
Nameplate Voltage
380-480V AC
Fluid Connection Size
2 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GRACO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GRACO Electric Diaphragm Pump with Aluminum Body is an aluminum housing EODD pump featuring a 2-inch NPT fluid connection. It operates with a nameplate voltage of 380-480V AC and includes 303 SS seat material. This pump is identified by manufacturer part number TE120-1114.

Frequently Asked Questions

What is the GRACO Electric Diaphragm Pump TE120-1114 used for?

The GRACO Electric Diaphragm Pump TE120-1114 is used for transferring and dosing fluids in industrial processes such as chemical processing, water treatment, and paint circulation. Its aluminum body and 303 SS seats make it suitable for handling a range of non-aggressive liquids in demanding environments.

What are the specifications of the GRACO Electric Diaphragm Pump TE120-1114?

The GRACO Electric Diaphragm Pump TE120-1114 features an aluminum housing, a 2-inch NPT fluid connection size, and 303 SS seat material. It operates on a nameplate voltage of 380-480V AC. The manufacturer part number is TE120-1114, and it is classified as an aluminum housing EODD pump.

Where to buy the GRACO Electric Diaphragm Pump TE120-1114 worldwide?

You can source the GRACO Electric Diaphragm Pump TE120-1114 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine GRACO pumps to procurement teams globally.

How to select the right GRACO Electric Diaphragm Pump for your application?

To select the right GRACO Electric Diaphragm Pump, match the fluid connection size (e.g., 2-inch NPT), voltage requirements (380-480V AC), and wetted materials (aluminum body, 303 SS seats) to your fluid type and pressure needs. Consult the pump's performance curve and ensure compatibility with your system's flow rate and viscosity.

Used in

Common applications for GRACO
Food and beverage processing — Graco FDA-compliant electric diaphragm pumps (e.g., HE120-1200) for sanitary fluid transfer
Pharmaceutical manufacturing — Graco USP Class VI-compliant AODD pumps (e.g., SP4F.0006) for sterile liquid handling
Chemical processing — Graco aluminum or stainless steel diaphragm pumps (e.g., TE120-1100) for corrosive fluid transfer
Automotive lubrication — Graco grease pump control replacement kits (e.g., 18F169) for maintenance of lubrication systems
Paint and coating application — Graco discharge spouts (e.g., 255858) for precise fluid dispensing in finishing lines
Water and wastewater treatment — Graco electric diaphragm pumps (e.g., HE120-1503) for sludge and chemical dosing
