GRACO Electric Diaphragm Pump: Cast Iron Body, 2 in Fluid Connection Size - Stainless Steel Housing EODD Pumps
GRACOStainless Steel Housing EODD Pumps

GRACO Electric Diaphragm Pump: Cast Iron Body, 2 in Fluid Connection Size

The GRACO Electric Diaphragm Pump with Cast Iron Body (MPN TE120-1601) is a stainless steel housing EODD pump featuring a 2-inch NPT fluid connection. It operates with a nameplate voltage of 380-480V AC and includes…

SKU 3G-OTH-86302

Brand
GRACO
Item
Electric Diaphragm Pump: Cast Iron Body, 2 in Fluid Connection Size
Category
Stainless Steel Housing EODD Pumps
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GRACO
Manufacturer Part Number
TE120-1601
Type
NPT Connection
Seat Material
Santoprene
Nameplate Voltage
380-480V AC
Check Valve Material
Santoprene
Fluid Connection Size
2 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GRACO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GRACO Electric Diaphragm Pump with Cast Iron Body (MPN TE120-1601) is a stainless steel housing EODD pump featuring a 2-inch NPT fluid connection. It operates with a nameplate voltage of 380-480V AC and includes Santoprene check valve and seat materials.

Frequently Asked Questions

What is the GRACO Electric Diaphragm Pump TE120-1601 used for?

The GRACO Electric Diaphragm Pump TE120-1601 is used for transferring fluids in industrial applications requiring a 2-inch NPT connection. Its Santoprene check valve and seat materials make it suitable for handling abrasive or corrosive fluids in sectors like chemical processing, water treatment, and manufacturing.

What are the specifications of the GRACO TE120-1601 pump?

The GRACO TE120-1601 is an electric diaphragm pump with a cast iron body and stainless steel housing. It has a 2-inch NPT fluid connection, operates at 380-480V AC, and features Santoprene check valve and seat materials. The manufacturer part number is TE120-1601.

Where to buy the GRACO TE120-1601 pump worldwide?

3G Electric supplies the GRACO TE120-1601 electric diaphragm pump to customers worldwide. We handle full logistics, customs clearance, and delivery to your location. Contact us for a quote and lead time on this pump.

How to select the right GRACO electric diaphragm pump?

To select the right GRACO electric diaphragm pump, match the fluid connection size (2-inch NPT), voltage (380-480V AC), and material compatibility (Santoprene for check valve and seat) with your application. Consult a technical specialist to confirm flow rate and pressure requirements.

Used in

Common applications for GRACO
Food and beverage processing — Graco FDA-compliant electric diaphragm pumps (e.g., HE120-1200) for sanitary fluid transfer
Pharmaceutical manufacturing — Graco USP Class VI-compliant AODD pumps (e.g., SP4F.0006) for sterile liquid handling
Chemical processing — Graco aluminum or stainless steel diaphragm pumps (e.g., TE120-1100) for corrosive fluid transfer
Automotive lubrication — Graco grease pump control replacement kits (e.g., 18F169) for maintenance of lubrication systems
Paint and coating application — Graco discharge spouts (e.g., 255858) for precise fluid dispensing in finishing lines
Water and wastewater treatment — Graco electric diaphragm pumps (e.g., HE120-1503) for sludge and chemical dosing
