GRACO Electric Diaphragm Pump: Aluminum Body, 1 1/2 in Fluid Connection Size - Aluminum Housing EODD Pumps
GRACOAluminum Housing EODD Pumps

GRACO Electric Diaphragm Pump: Aluminum Body, 1 1/2 in Fluid Connection Size

The GRACO Electric Diaphragm Pump with Aluminum Body is an aluminum housing EODD pump (SKU 411WL1, MPN TE80-1000). It features a 1 1/2 in NPT fluid connection, a nameplate voltage of 380-480V AC, and Buna-N check…

SKU 3G-OTH-88025

Brand
GRACO
Item
Electric Diaphragm Pump: Aluminum Body, 1 1/2 in Fluid Connection Size
Category
Aluminum Housing EODD Pumps
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GRACO
Manufacturer Part Number
TE80-1000
Type
NPT Connection
Seat Material
Buna-N
Nameplate Voltage
380-480V AC
Check Valve Material
Buna-N
Fluid Connection Size
1 1/2 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GRACO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GRACO Electric Diaphragm Pump with Aluminum Body is an aluminum housing EODD pump (SKU 411WL1, MPN TE80-1000). It features a 1 1/2 in NPT fluid connection, a nameplate voltage of 380-480V AC, and Buna-N check valve and seat materials.

Frequently Asked Questions

What is the GRACO Electric Diaphragm Pump TE80-1000 used for?

The GRACO Electric Diaphragm Pump TE80-1000 is used for transferring fluids in industrial applications such as chemical processing, paint circulation, and wastewater handling. Its aluminum body and Buna-N check valve and seat materials make it suitable for non-aggressive fluids like oils, water-based coatings, and mild chemicals.

What are the specifications of the GRACO TE80-1000 electric diaphragm pump?

The GRACO TE80-1000 is an aluminum housing EODD pump with a 1 1/2 in NPT fluid connection and a nameplate voltage of 380-480V AC. It features Buna-N check valve and seat materials. The manufacturer part number is TE80-1000, and the SKU is 411WL1.

Where to buy the GRACO TE80-1000 electric diaphragm pump worldwide?

You can source the GRACO TE80-1000 electric diaphragm pump worldwide through 3G Electric. As a global industrial equipment distributor since 1990, 3G Electric handles full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to select the right GRACO electric diaphragm pump for my application?

To select the right GRACO electric diaphragm pump, consider fluid compatibility, connection size, and voltage. The TE80-1000 with Buna-N materials suits oils and mild chemicals. For aggressive fluids, choose pumps with alternative elastomers. Verify your power supply matches the 380-480V AC nameplate voltage. Consult 3G Electric for guidance.
