GRACO Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 240V AC, 2 in - FDA-Compliant EODD Pumps
GRACOFDA-Compliant EODD Pumps

GRACO Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 240V AC, 2 in

The GRACO Electric Diaphragm Pump (SKU 822EM7, MPN HE80-0005) is an FDA-compliant EODD pump with a stainless steel body. It operates on three-phase 240V AC power, features PTFE check valves and SS seat material, and…

SKU 3G-OTH-90006

Brand
GRACO
Item
Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 240V AC, 2 in
Category
FDA-Compliant EODD Pumps
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GRACO
Manufacturer Part Number
HE80-0005
Type
Three Phase, 2 in
AC
240V
Max. Flow
80 gpm
Seat Material
SS
Nameplate Voltage
240V AC
Check Valve Material
PTFE
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GRACO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GRACO Electric Diaphragm Pump (SKU 822EM7, MPN HE80-0005) is an FDA-compliant EODD pump with a stainless steel body. It operates on three-phase 240V AC power, features PTFE check valves and SS seat material, and delivers a maximum flow of 80 gpm with a 2-inch connection.

Frequently Asked Questions

What is the GRACO Electric Diaphragm Pump HE80-0005 used for?

The GRACO HE80-0005 is an FDA-compliant EODD pump designed for sanitary transfer of fluids in food, beverage, and pharmaceutical applications. Its stainless steel body and PTFE check valves meet hygiene standards, while the 80 gpm flow and 2-inch connection handle medium-volume processing.

What are the specifications of the GRACO HE80-0005 pump?

The GRACO HE80-0005 is a three-phase electric diaphragm pump with a 240V AC nameplate voltage. It delivers a maximum flow of 80 gpm through a 2-inch connection. The body is stainless steel, check valves are PTFE, and seat material is SS. It is FDA-compliant for sanitary applications.

Where to buy the GRACO HE80-0005 pump worldwide?

3G Electric supplies the GRACO HE80-0005 electric diaphragm pump to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this FDA-compliant EODD pump.

How to select the right GRACO EODD pump for my application?

Selecting the right GRACO EODD pump requires matching flow rate (up to 80 gpm for the HE80-0005), connection size (2 inches), and power supply (240V AC three-phase). For FDA-compliant needs, ensure materials like stainless steel and PTFE suit your fluid. Consult 3G Electric for application guidance.

Used in

Common applications for GRACO
Food and beverage processing — Graco FDA-compliant electric diaphragm pumps (e.g., HE120-1200) for sanitary fluid transfer
Pharmaceutical manufacturing — Graco USP Class VI-compliant AODD pumps (e.g., SP4F.0006) for sterile liquid handling
Chemical processing — Graco aluminum or stainless steel diaphragm pumps (e.g., TE120-1100) for corrosive fluid transfer
Automotive lubrication — Graco grease pump control replacement kits (e.g., 18F169) for maintenance of lubrication systems
Paint and coating application — Graco discharge spouts (e.g., 255858) for precise fluid dispensing in finishing lines
Water and wastewater treatment — Graco electric diaphragm pumps (e.g., HE120-1503) for sludge and chemical dosing
