Grundfos Circulating Pump: 1 51/125 hp HP, 230V AC, Cast Iron, 3, 23 ft Max. Head - General-Purpose Inline Circulator Pumps
GrundfosGeneral-Purpose Inline Circulator Pumps

Grundfos Circulating Pump: 1 51/125 hp HP, 230V AC, Cast Iron, 3, 23 ft Max. Head

The Grundfos Circulating Pump (SKU 856AK9) is a general-purpose inline circulator pump designed for potable water systems. This standard-efficiency unit features a 230V AC nameplate voltage, flange connections, and…

SKU 3G-OTH-84221

Brand
Grundfos
Item
Circulating Pump: 1 51/125 hp HP, 230V AC, Cast Iron, 3, 23 ft Max. Head
Category
General-Purpose Inline Circulator Pumps
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Grundfos
Manufacturer Part Number
96654378
Type
Cast Iron, 3, 14 1/4 in Face to Face
AC
230V
Max. Head
23 ft
Efficiency
Standard Efficiency
System Type
Potable Water
Connection Type
Flange
Includes Volute
Volute Included
Nameplate Voltage
230V AC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Grundfos Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Grundfos Circulating Pump (SKU 856AK9) is a general-purpose inline circulator pump designed for potable water systems. This standard-efficiency unit features a 230V AC nameplate voltage, flange connections, and includes a volute. It delivers a maximum head of 23 ft with a face-to-face dimension of 14 1/4 in, and is constructed with cast iron.

Frequently Asked Questions

What is the Grundfos 96654378 circulating pump used for?

The Grundfos 96654378 is a general-purpose inline circulator pump designed for potable water systems. It is used to circulate water in heating, cooling, or domestic water loops where a standard-efficiency, flange-connected pump with a 23 ft maximum head is required.

What are the specifications of the Grundfos 96654378 pump?

The Grundfos 96654378 pump has a 230V AC nameplate voltage, cast iron construction, flange connections, and a 14 1/4 in face-to-face dimension. It delivers a maximum head of 23 ft, includes a volute, and is rated for standard efficiency in potable water systems.

Where to buy the Grundfos 96654378 circulating pump worldwide?

3G Electric supplies the Grundfos 96654378 circulating pump to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this standard-efficiency, 230V AC inline circulator.

How to install a Grundfos inline circulator pump?

Install the Grundfos inline circulator pump with the shaft horizontal and the electrical box accessible. Use flange gaskets and bolts per the system pressure rating. Wire the 230V AC motor per local codes, and purge air from the volute before startup. Always follow the manufacturer's manual.
