HAM-LET Compression Fitting Elbow: 1/2 in OD x 3/8 in Pipe Fitting Size - Double-Ferrule Stainless Steel Fittings
HAM-LETDouble-Ferrule Stainless Steel Fittings

HAM-LET Compression Fitting Elbow: 1/2 in OD x 3/8 in Pipe Fitting Size

The HAM-LET Compression Fitting Elbow (MPN 769L SS 1/2 X 3/8) is a double-ferrule stainless steel fitting with a 1/2 in OD x 3/8 in pipe fitting size and Compression x MNPT configuration. It is compatible with…

SKU 3G-OTH-471428

Brand
HAM-LET
Item
Compression Fitting Elbow: 1/2 in OD x 3/8 in Pipe Fitting Size
Category
Double-Ferrule Stainless Steel Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HAM-LET
Manufacturer Part Number
769L SS 1/2 X 3/8
Type
Compression x MNPT
Compatible Fitting Brands
Let-Lok
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HAM-LET Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HAM-LET Compression Fitting Elbow (MPN 769L SS 1/2 X 3/8) is a double-ferrule stainless steel fitting with a 1/2 in OD x 3/8 in pipe fitting size and Compression x MNPT configuration. It is compatible with Let-Lok fitting brands.

Frequently Asked Questions

What is a HAM-LET compression fitting elbow used for?

A HAM-LET double-ferrule stainless steel compression fitting elbow connects tubing to threaded ports in industrial instrumentation, hydraulic, and pneumatic systems. Its 1/2 in OD x 3/8 in pipe size and Compression x MNPT design provides a leak-tight seal in high-pressure fluid or gas lines.

What are the specifications of the HAM-LET 769L SS 1/2 X 3/8 elbow?

The HAM-LET 769L SS 1/2 X 3/8 is a double-ferrule stainless steel compression fitting elbow. It has a 1/2 in OD tube size and 3/8 in pipe fitting size, with Compression x MNPT connection. It is compatible with Let-Lok fitting brands and is manufactured by HAM-LET.

Where to buy HAM-LET compression fittings worldwide?

3G Electric supplies HAM-LET compression fittings worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us to source the HAM-LET 769L SS 1/2 X 3/8 elbow or other double-ferrule stainless steel fittings for your application.

How to install a HAM-LET double-ferrule compression fitting?

To install a HAM-LET double-ferrule compression fitting, insert the tube fully into the fitting, then tighten the nut by hand. Use a wrench to tighten an additional 1-1/4 turns for 1/2 in OD tubing. Always follow manufacturer guidelines and use proper tube support to avoid leaks.

Used in

Common applications for HAM-LET
Oil and gas — HAM-LET H99 Series needle valves for instrument isolation in high-pressure lines
Chemical processing — HAM-LET H-400 Series check valves for backflow prevention in corrosive fluid systems
Semiconductor manufacturing — HAM-LET EVZS4R-BV diaphragm valves for ultra-high-purity gas distribution
Power generation — HAM-LET H-6800 Series three-way ball valves for cooling water flow switching
Analytical instrumentation — HAM-LET H300U Series metering valves for precise flow regulation in lab gas systems
Hydraulic systems — HAM-LET H-410 Series poppet check valves for load-holding in hydraulic circuits
