HAM-LET Compression Fitting Elbow: 10 mm OD x 1/4 in Pipe Fitting Size - Double-Ferrule Stainless Steel Fittings
HAM-LETDouble-Ferrule Stainless Steel Fittings

HAM-LET Compression Fitting Elbow: 10 mm OD x 1/4 in Pipe Fitting Size

The HAM-LET Compression Fitting Elbow (MPN 769L-SS 10MM X 1/4) is a double-ferrule stainless steel fitting with a 10 mm OD tube size and 1/4 in MNPT pipe connection. It is compatible with Swagelok fittings…

SKU 3G-OTH-471384

Brand
HAM-LET
Item
Compression Fitting Elbow: 10 mm OD x 1/4 in Pipe Fitting Size
Category
Double-Ferrule Stainless Steel Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HAM-LET
Manufacturer Part Number
769L-SS 10MM X 1/4
Type
Compression x MNPT
Compatible Fitting Brands
Swagelok
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HAM-LET Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HAM-LET Compression Fitting Elbow (MPN 769L-SS 10MM X 1/4) is a double-ferrule stainless steel fitting with a 10 mm OD tube size and 1/4 in MNPT pipe connection. It is compatible with Swagelok fittings, supporting reliable compression x MNPT configurations in industrial tubing systems.

Frequently Asked Questions

What is a HAM-LET compression fitting elbow used for?

A HAM-LET compression fitting elbow connects 10 mm OD tubing to a 1/4 in MNPT threaded port at a 90-degree angle. It is used in industrial instrumentation, hydraulic, and pneumatic systems where a leak-tight, vibration-resistant joint is required. The double-ferrule design provides reliable sealing in high-pressure tubing applications.

What are the specifications of the HAM-LET 769L-SS 10MM X 1/4?

The HAM-LET 769L-SS 10MM X 1/4 is a double-ferrule stainless steel compression elbow. It has a 10 mm OD tube size and a 1/4 in MNPT pipe connection. The fitting is compatible with Swagelok brands and is designed for compression x MNPT configurations in industrial tubing systems.

Where to buy HAM-LET compression fittings worldwide?

3G Electric supplies HAM-LET compression fittings worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us to source the HAM-LET 769L-SS 10MM X 1/4 or any other genuine industrial fitting for your application.

How to install a HAM-LET double-ferrule compression fitting?

To install a HAM-LET double-ferrule compression fitting, insert the tube fully into the fitting body, then tighten the nut finger-tight. Mark the nut position, then tighten an additional 1-1/4 turns for 10 mm OD tubing. Always use a proper tube cutter and deburr the tube end before assembly to ensure a leak-free seal.
