HAM-LET Compression Fitting Elbow: 12 mm OD x 3/8 in Pipe Fitting Size - Double-Ferrule Stainless Steel Fittings
HAM-LETDouble-Ferrule Stainless Steel Fittings

HAM-LET Compression Fitting Elbow: 12 mm OD x 3/8 in Pipe Fitting Size

The HAM-LET Compression Fitting Elbow (MPN 769L-SS-12MM X 3/8) is a double-ferrule stainless steel fitting with a 12 mm OD tube size and 3/8 in MNPT pipe thread. It is compatible with Let-Lok fitting brands and is…

SKU 3G-OTH-471823

Brand
HAM-LET
Item
Compression Fitting Elbow: 12 mm OD x 3/8 in Pipe Fitting Size
Category
Double-Ferrule Stainless Steel Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HAM-LET
Manufacturer Part Number
769L-SS-12MM X 3/8
Type
Compression x MNPT
Compatible Fitting Brands
Let-Lok
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HAM-LET Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HAM-LET Compression Fitting Elbow (MPN 769L-SS-12MM X 3/8) is a double-ferrule stainless steel fitting with a 12 mm OD tube size and 3/8 in MNPT pipe thread. It is compatible with Let-Lok fitting brands and is supplied as a Compression x MNPT configuration.

Frequently Asked Questions

What is a HAM-LET compression fitting elbow used for?

A HAM-LET compression fitting elbow connects 12 mm OD tubing to a 3/8 in MNPT threaded port at a 90° angle. It is used in instrumentation, hydraulic, and process systems where a leak-tight, vibration-resistant joint is required. The double-ferrule design ensures reliable sealing in high-pressure applications.

What are the specifications of the HAM-LET 769L-SS-12MM X 3/8?

The HAM-LET 769L-SS-12MM X 3/8 is a double-ferrule stainless steel elbow with a 12 mm OD tube size and 3/8 in MNPT pipe thread. It is a Compression x MNPT configuration, compatible with Let-Lok fitting brands. The part is manufactured by HAM-LET and is suitable for demanding industrial environments.

Where to buy HAM-LET compression fittings in worldwide?

3G Electric supplies HAM-LET compression fittings like the 769L-SS-12MM X 3/8 to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this double-ferrule stainless steel elbow.

How to install a HAM-LET double-ferrule compression fitting?

To install a HAM-LET double-ferrule compression fitting, cut tubing squarely, deburr the end, and slide the nut and ferrules onto the tube. Insert the tube fully into the fitting body, then tighten the nut by hand. Use a wrench to tighten an additional 1-1/4 turns for proper ferrule bite. Always follow manufacturer guidelines for torque.

Used in

Common applications for HAM-LET
Oil and gas — HAM-LET H99 Series needle valves for instrument isolation in high-pressure lines
Chemical processing — HAM-LET H-400 Series check valves for backflow prevention in corrosive fluid systems
Semiconductor manufacturing — HAM-LET EVZS4R-BV diaphragm valves for ultra-high-purity gas distribution
Power generation — HAM-LET H-6800 Series three-way ball valves for cooling water flow switching
Analytical instrumentation — HAM-LET H300U Series metering valves for precise flow regulation in lab gas systems
Hydraulic systems — HAM-LET H-410 Series poppet check valves for load-holding in hydraulic circuits

HAM-LET Products

3G Electric supplies HAM-LET double-ferrule stainless steel fittings. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
