HAM-LET Compression Fitting Adapter: 20 mm OD x 1/2 in Pipe Fitting Size - Double-Ferrule Stainless Steel Fittings
HAM-LETDouble-Ferrule Stainless Steel Fittings

HAM-LET Compression Fitting Adapter: 20 mm OD x 1/2 in Pipe Fitting Size

The HAM-LET Compression Fitting Adapter (MPN 766L SS 20MMX 1/2) is a double-ferrule stainless steel fitting with a 20 mm OD tube end and a 1/2 in FNPT pipe thread. It is compatible with Swagelok fitting brands…

SKU 3G-OTH-471443

Brand
HAM-LET
Item
Compression Fitting Adapter: 20 mm OD x 1/2 in Pipe Fitting Size
Category
Double-Ferrule Stainless Steel Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HAM-LET
Manufacturer Part Number
766L SS 20MMX 1/2
Type
Compression x FNPT
Compatible Fitting Brands
Swagelok
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HAM-LET Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HAM-LET Compression Fitting Adapter (MPN 766L SS 20MMX 1/2) is a double-ferrule stainless steel fitting with a 20 mm OD tube end and a 1/2 in FNPT pipe thread. It is compatible with Swagelok fitting brands, enabling secure connections in industrial fluid systems.

Frequently Asked Questions

What is a HAM-LET compression fitting adapter used for?

A HAM-LET compression fitting adapter connects 20 mm OD tubing to a 1/2 in FNPT threaded port in industrial fluid systems. Its double-ferrule stainless steel design provides a leak-tight seal, making it suitable for instrumentation, chemical processing, and hydraulic applications where Swagelok-compatible connections are required.

What are the specifications of the HAM-LET 766L SS 20MMX 1/2?

The HAM-LET 766L SS 20MMX 1/2 is a double-ferrule stainless steel compression fitting adapter. It has a 20 mm OD tube end and a 1/2 in FNPT pipe thread. The fitting is compatible with Swagelok brands and is designed for secure, leak-resistant connections in industrial fluid systems.

Where to buy HAM-LET compression fittings worldwide?

3G Electric supplies HAM-LET compression fittings like the 766L SS 20MMX 1/2 to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this double-ferrule stainless steel adapter.

How to install a HAM-LET double-ferrule compression fitting?

To install a HAM-LET double-ferrule fitting, insert the tube fully into the fitting body, then tighten the nut finger-tight. Mark the nut position, then tighten an additional 1-1/4 turns for 20 mm OD tubing. Always use a Swagelok-compatible gauge to verify proper ferrule engagement and avoid over-tightening.

Used in

Common applications for HAM-LET
Oil and gas — HAM-LET H99 Series needle valves for instrument isolation in high-pressure lines
Chemical processing — HAM-LET H-400 Series check valves for backflow prevention in corrosive fluid systems
Semiconductor manufacturing — HAM-LET EVZS4R-BV diaphragm valves for ultra-high-purity gas distribution
Power generation — HAM-LET H-6800 Series three-way ball valves for cooling water flow switching
Analytical instrumentation — HAM-LET H300U Series metering valves for precise flow regulation in lab gas systems
Hydraulic systems — HAM-LET H-410 Series poppet check valves for load-holding in hydraulic circuits
