HAYWARD Butterfly Valve: 12 in Pipe Size, Concentric, 150 psi Max. Pressure (CWP) - PVC General-Service Butterfly Valves
HAYWARDPVC General-Service Butterfly Valves

HAYWARD Butterfly Valve: 12 in Pipe Size, Concentric, 150 psi Max. Pressure (CWP)

The HAYWARD Butterfly Valve is a 12-inch PVC general-service butterfly valve with a gear-operated handwheel. It features a concentric design, a PVC disc, and a wafer-style body, rated for a maximum pressure of 150…

SKU 3G-OTH-439897

Brand
HAYWARD
Item
Butterfly Valve: 12 in Pipe Size, Concentric, 150 psi Max. Pressure
Category
PVC General-Service Butterfly Valves
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HAYWARD
Manufacturer Part Number
BYV11120A0NG000
Type
Concentric, Wafer, PVC, PVC
Handle Type
Gear Operated Handwheel
Disc Material
PVC
Max. Pressure (CWP)
150 psi
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HAYWARD Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HAYWARD Butterfly Valve is a 12-inch PVC general-service butterfly valve with a gear-operated handwheel. It features a concentric design, a PVC disc, and a wafer-style body, rated for a maximum pressure of 150 psi (CWP). This valve is identified by manufacturer part number BYV11120A0NG000.

Frequently Asked Questions

What is the HAYWARD butterfly valve used for?

The HAYWARD butterfly valve is used for on-off or throttling flow control of general-service fluids in industrial piping systems. Its PVC construction makes it suitable for corrosive environments, water treatment, chemical processing, and irrigation applications where a 12-inch line size and 150 psi CWP rating are required.

What are the specifications of the HAYWARD butterfly valve?

This HAYWARD butterfly valve has a 12-inch pipe size, concentric design, wafer-style body, and a PVC disc. It is rated for 150 psi CWP and features a gear-operated handwheel handle. The manufacturer part number is BYV11120A0NG000. It is a PVC general-service butterfly valve.

Where to buy the HAYWARD butterfly valve worldwide?

You can source the HAYWARD butterfly valve through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this PVC general-service butterfly valve.

How to install a HAYWARD butterfly valve?

Install the HAYWARD butterfly valve between two pipe flanges using the wafer-style body. Ensure the valve is fully open during installation to avoid disc damage. Align the bolt holes, tighten bolts evenly in a cross pattern to the manufacturer's torque specs, and verify the gear-operated handwheel operates smoothly before pressurizing.

Used in

Common applications for HAYWARD
Chemical processing — Hayward CPVC butterfly valves (PCSBYV series) for corrosive chemical flow control
Water treatment — Hayward glass-filled polypropylene butterfly valves (BYV series) for general-service water lines
Industrial filtration — Hayward CPVC Y strainers (YS series) for removing particulates from process fluids
Automated valve control — Hayward pneumatic actuators (PSD series) for remote operation of quarter-turn valves
Solenoid valve applications — Hayward 2-way solenoid valves (SV series) for on/off control of water or mild chemicals
