HAYWARD Butterfly Valve: 12 in Pipe Size, Concentric, 150 psi Max. Pressure (CWP) - PVC General-Service Butterfly Valves
HAYWARDPVC General-Service Butterfly Valves

HAYWARD Butterfly Valve: 12 in Pipe Size, Concentric, 150 psi Max. Pressure (CWP)

The HAYWARD Butterfly Valve is a 12-inch PVC general-service butterfly valve with a gear-operated handwheel handle. It features a concentric design, a PVC disc, and a lug-style body, rated for a maximum pressure of…

SKU 3G-OTH-439904

Brand
HAYWARD
Item
Butterfly Valve: 12 in Pipe Size, Concentric, 150 psi Max. Pressure
Category
PVC General-Service Butterfly Valves
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HAYWARD
Manufacturer Part Number
BYV11120A0VGI00
Type
Concentric, Lug, PVC, PVC
Handle Type
Gear Operated Handwheel
Disc Material
PVC
Max. Pressure (CWP)
150 psi
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HAYWARD Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HAYWARD Butterfly Valve is a 12-inch PVC general-service butterfly valve with a gear-operated handwheel handle. It features a concentric design, a PVC disc, and a lug-style body, rated for a maximum pressure of 150 psi (CWP). This valve is identified by manufacturer part number BYV11120A0VGI00.

Frequently Asked Questions

What is the HAYWARD BYV11120A0VGI00 butterfly valve used for?

The HAYWARD BYV11120A0VGI00 is a 12-inch PVC general-service butterfly valve used for on-off or throttling control of compatible fluids in industrial piping systems. Its lug-style body allows dead-end service, making it suitable for water treatment, chemical processing, and HVAC applications where corrosion resistance is required.

What are the specifications of the HAYWARD BYV11120A0VGI00 butterfly valve?

The HAYWARD BYV11120A0VGI00 is a 12-inch, concentric butterfly valve with a PVC body and disc, rated for 150 psi CWP. It features a gear-operated handwheel handle and a lug-style design. The manufacturer part number is BYV11120A0VGI00. This valve is intended for general-service applications requiring corrosion resistance.

Where to buy the HAYWARD BYV11120A0VGI00 butterfly valve worldwide?

3G Electric supplies the HAYWARD BYV11120A0VGI00 butterfly valve worldwide. As a global industrial equipment distributor established in 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time; we source and deliver this HAYWARD valve to any international destination.

How to install a HAYWARD PVC butterfly valve?

To install a HAYWARD PVC butterfly valve, ensure the pipe ends are clean and align the valve lug holes with the flange bolts. Tighten bolts evenly in a cross pattern to the torque recommended by the gasket manufacturer. Do not over-tighten, as PVC can crack. Use the gear-operated handwheel to cycle the valve fully after installation to verify smooth operation.

Used in

Common applications for HAYWARD
Chemical processing — Hayward CPVC butterfly valves (PCSBYV series) for corrosive chemical flow control
Water treatment — Hayward glass-filled polypropylene butterfly valves (BYV series) for general-service water lines
Industrial filtration — Hayward CPVC Y strainers (YS series) for removing particulates from process fluids
Automated valve control — Hayward pneumatic actuators (PSD series) for remote operation of quarter-turn valves
Solenoid valve applications — Hayward 2-way solenoid valves (SV series) for on/off control of water or mild chemicals
