HAYWARD Diaphragm Valve: 1/2 in, CPVC, 2-Way, NPT x Socket, 150 psi Max Pressure (CWP) - CPVC Diaphragm Valves for Chemicals with Position Indicators
HAYWARDCPVC Diaphragm Valves for Chemicals with Position Indicators

HAYWARD Diaphragm Valve: 1/2 in, CPVC, 2-Way, NPT x Socket, 150 psi Max Pressure (CWP)

The HAYWARD Diaphragm Valve is a 1/2 in CPVC diaphragm valve for chemicals, featuring a position indicator. This 2-way valve has NPT x Socket connections, a maximum pressure of 150 psi (CWP), and a PTFE diaphragm…

SKU 3G-OTH-448632

Brand
HAYWARD
Item
Diaphragm Valve: 1/2 in, CPVC, 2-Way, NPT x Socket, 150 psi Max Pressure
Category
CPVC Diaphragm Valves for Chemicals with Position Indicators
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HAYWARD
Manufacturer Part Number
DAB2005UPF
Type
CPVC, 2-Way, NPT x Socket, EPDM/PTFE
Special Features
Position Indicator
Diaphragm Material
PTFE
Max Pressure (CWP)
150 psi
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HAYWARD Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HAYWARD Diaphragm Valve is a 1/2 in CPVC diaphragm valve for chemicals, featuring a position indicator. This 2-way valve has NPT x Socket connections, a maximum pressure of 150 psi (CWP), and a PTFE diaphragm material (MPN DAB2005UPF).

Frequently Asked Questions

What is the HAYWARD diaphragm valve used for?

The HAYWARD diaphragm valve is used for on-off or throttling control of corrosive chemicals in industrial piping systems. Its CPVC body and PTFE diaphragm resist aggressive fluids, making it suitable for chemical processing, water treatment, and plating applications where leak-free isolation is required.

What are the specifications of the HAYWARD diaphragm valve DAB2005UPF?

The HAYWARD diaphragm valve DAB2005UPF is a 1/2 in, 2-way CPVC valve with NPT x Socket connections. It has a maximum pressure rating of 150 psi (CWP), a PTFE diaphragm, and a position indicator. The body material is CPVC, designed for chemical service.

Where to buy HAYWARD diaphragm valves worldwide?

3G Electric supplies HAYWARD diaphragm valves worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on the DAB2005UPF or other HAYWARD valve models.

How to install a HAYWARD CPVC diaphragm valve?

Install the HAYWARD CPVC diaphragm valve in a horizontal or vertical line with the valve stem upright. Use PTFE tape on NPT threads and solvent cement on socket ends per CPVC manufacturer instructions. Avoid over-tightening to prevent body stress. Verify the position indicator shows open or closed before pressurizing.

Used in

Common applications for HAYWARD
Chemical processing — Hayward CPVC butterfly valves (PCSBYV series) for corrosive chemical flow control
Water treatment — Hayward glass-filled polypropylene butterfly valves (BYV series) for general-service water lines
Industrial filtration — Hayward CPVC Y strainers (YS series) for removing particulates from process fluids
Automated valve control — Hayward pneumatic actuators (PSD series) for remote operation of quarter-turn valves
Solenoid valve applications — Hayward 2-way solenoid valves (SV series) for on/off control of water or mild chemicals

HAYWARD Products

3G Electric supplies HAYWARD cpvc diaphragm valves for chemicals with position indicators. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
