HEDLAND Mechanical Flowmeter: Petroleum Fluid Meter, Scale, Variable Area, Inline - Inline Flowmeters for Oils
HEDLANDInline Flowmeters for Oils

HEDLAND Mechanical Flowmeter: Petroleum Fluid Meter, Scale, Variable Area, Inline

The HEDLAND Mechanical Flowmeter is an inline variable-area flowmeter for petroleum fluids, featuring a scale display and universal mounting orientation. It offers +/-2% accuracy, uses Viton O-ring and seal…

SKU 3G-OTH-93171

Brand
HEDLAND
Item
Mechanical Flowmeter: Petroleum Fluid Meter, Scale, Variable Area, Inline
Category
Inline Flowmeters for Oils
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HEDLAND
Manufacturer Part Number
H800A-030
Type
Scale, Variable Area, Inline, Universal, SAE
Accuracy
+/-2%
Display Type
Scale
Seal Material
Viton
O-Ring Material
Viton
Unit Of Measure
Gallons
Mounting Orientation
Universal
Includes Pressure Guage
No
Includes Flow Rate Adjustment Knob
No
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HEDLAND Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HEDLAND Mechanical Flowmeter is an inline variable-area flowmeter for petroleum fluids, featuring a scale display and universal mounting orientation. It offers +/-2% accuracy, uses Viton O-ring and seal materials, and measures flow in gallons. This model (MPN H800A-030) does not include a pressure gauge or flow rate adjustment knob.

Frequently Asked Questions

What is the HEDLAND H800A-030 mechanical flowmeter used for?

The HEDLAND H800A-030 is an inline variable-area flowmeter designed to measure petroleum fluid flow rates in gallons. It is commonly used in industrial hydraulic and lubrication systems where reliable, mechanical flow indication is needed without electrical power.

What are the specifications of the HEDLAND H800A-030 flowmeter?

The HEDLAND H800A-030 is a scale-display, variable-area, inline flowmeter with SAE connections. It offers +/-2% accuracy, uses Viton O-ring and seal materials, mounts in any orientation, and measures flow in gallons. It does not include a pressure gauge or flow adjustment knob.

Where to buy the HEDLAND H800A-030 flowmeter worldwide?

3G Electric supplies the HEDLAND H800A-030 mechanical flowmeter to customers worldwide. As a global industrial sourcing partner, we handle logistics, customs clearance, and delivery to your location. Contact us for pricing and lead time on this model.

How to install the HEDLAND H800A-030 flowmeter?

Install the HEDLAND H800A-030 inline in the petroleum fluid line with flow direction matching the arrow on the body. Ensure Viton seals are compatible with the fluid. Mount in any orientation, but avoid excessive vibration. Tighten connections to manufacturer torque specs and check for leaks before operation.
