HELI-COIL Helical Insert: Tanged Tang Style, Free-Running, M5-0.80 Thread Size, Plain - Free-Running Tanged Helical Inserts
HELI-COILFree-Running Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Free-Running, M5-0.80 Thread Size, Plain

The HELI-COIL Helical Insert is a free-running, tanged tang style insert with M5-0.80 thread size, right-hand, coarse metric threads, made of Nitronic 60 metal, offering 200,000 psi tensile strength, 5.2mm length…

SKU 3G-OTH-599138

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Free-Running, M5-0.80 Thread Size, Plain
Category
Free-Running Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
A1084-5EN050
Type
Free-Running, M5-0.80 Thread Size, Plain, Plain, 100 PK
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HELI-COIL Helical Insert is a free-running, tanged tang style insert with M5-0.80 thread size, right-hand, coarse metric threads, made of Nitronic 60 metal, offering 200,000 psi tensile strength, 5.2mm length, plain finish, in a 100-piece pack (MPN A1084-5EN050).

Frequently Asked Questions

What is a HELI-COIL helical insert used for?

A HELI-COIL helical insert repairs or reinforces threads in metal. This free-running tanged tang style, M5-0.80, Nitronic 60 insert provides strong, wear-resistant threads in aluminum, cast iron, or steel components across machining, automotive, and industrial maintenance applications.

What are the specifications of the HELI-COIL A1084-5EN050 insert?

This HELI-COIL insert has M5-0.80 thread size, right-hand coarse metric threads, 5.2mm length, 200,000 psi tensile strength, plain finish, and is made of Nitronic 60 metal. It comes in a 100-piece pack (MPN A1084-5EN050) and is designed for free-running tanged tang installation.

Where to buy HELI-COIL helical inserts worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver genuine HELI-COIL products like the A1084-5EN050 to your facility. Contact us for pricing and lead time on your order.

How to install a tanged HELI-COIL insert?

To install a tanged HELI-COIL insert, drill to the specified tap drill size, tap the hole with the correct HELI-COIL tap, then use the installation tool to wind the insert into the threaded hole. Break off the tang after installation. Always follow the manufacturer's instructions for best results.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates

HELI-COIL Products

3G Electric supplies HELI-COIL free-running tanged helical inserts. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
