HELI-COIL Thread Repair Kit: Tanged Tang Style, Free-Running, 1/4"-28 Thread Size - Insert & Tool Kits
HELI-COILInsert & Tool Kits

HELI-COIL Thread Repair Kit: Tanged Tang Style, Free-Running, 1/4"-28 Thread Size

The HELI-COIL Thread Repair Kit (MPN 5402-4) is a tanged tang style kit for free-running, stainless steel helical inserts. It includes a 1/4"-28 STI tap and inserts with a fine, right-hand thread, made from 18-8…

SKU 3G-OTH-527866

Brand
HELI-COIL
Item
Thread Repair Kit: Tanged Tang Style, Free-Running, 1/4"-28 Thread Size
Category
Insert & Tool Kits
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
5402-4
Type
Free-Running, Stainless Steel
Finish Type
Plain
Thread Size
1/4"-28
Thread Type
Fine
STI Tap Size
1/4"-28
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
Insert Types Included
Helical Inserts
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HELI-COIL Thread Repair Kit (MPN 5402-4) is a tanged tang style kit for free-running, stainless steel helical inserts. It includes a 1/4"-28 STI tap and inserts with a fine, right-hand thread, made from 18-8 stainless steel for metal repair. This inch-system kit is designed for restoring damaged threads in metal components.

Frequently Asked Questions

What is a HELI-COIL thread repair kit used for?

A HELI-COIL thread repair kit restores damaged internal threads in metal components. It uses 18-8 stainless steel helical inserts to create strong, free-running threads, ideal for automotive, industrial, and maintenance applications where original threads are stripped or worn.

What are the specifications of the HELI-COIL 5402-4 kit?

The HELI-COIL 5402-4 kit includes a 1/4"-28 STI tap and tanged tang style helical inserts. It features free-running, fine right-hand threads in 18-8 stainless steel, compatible with metal substrates. The kit uses inch-system measurements and is plain finish.

Where to buy HELI-COIL thread repair kits worldwide?

3G Electric supplies HELI-COIL thread repair kits worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver the 5402-4 kit and other thread repair products to your facility, regardless of location.

How to install a HELI-COIL thread insert?

To install a HELI-COIL insert, drill out the damaged thread to the specified size, tap the hole using the included STI tap, then wind the insert onto the installation tool and thread it into the tapped hole. Break off the tang after installation for a permanent repair.
