HELI-COIL Thread Repair Kit: Tanged Tang Style, Free-Running, 5/8"-11 Thread Size - Insert & Tool Kits
HELI-COILInsert & Tool Kits

HELI-COIL Thread Repair Kit: Tanged Tang Style, Free-Running, 5/8"-11 Thread Size

The HELI-COIL Thread Repair Kit (MPN 5401-10) is a tanged tang style kit for free-running, stainless steel helical inserts. It includes a 5/8"-11 coarse thread, right-hand direction, with an STI tap size of 5/8"-18…

SKU 3G-OTH-528117

Brand
HELI-COIL
Item
Thread Repair Kit: Tanged Tang Style, Free-Running, 5/8"-11 Thread Size
Category
Insert & Tool Kits
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
5401-10
Type
Free-Running, Stainless Steel
Finish Type
Plain
Thread Size
5/8"-11
Thread Type
Coarse
STI Tap Size
5/8"-18
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
Insert Types Included
Helical Inserts
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HELI-COIL Thread Repair Kit (MPN 5401-10) is a tanged tang style kit for free-running, stainless steel helical inserts. It includes a 5/8"-11 coarse thread, right-hand direction, with an STI tap size of 5/8"-18, made from 18-8 material grade, and is compatible with metal substrates.

Frequently Asked Questions

What is the HELI-COIL Thread Repair Kit 5401-10 used for?

The HELI-COIL Thread Repair Kit 5401-10 is used to restore damaged internal threads in metal components. It installs 18-8 stainless steel helical inserts for a 5/8"-11 coarse thread, providing a durable, free-running repair in industrial machinery, automotive, and maintenance applications.

What are the specifications of the HELI-COIL 5401-10 kit?

The HELI-COIL 5401-10 kit includes tanged tang style helical inserts with a 5/8"-11 coarse thread, right-hand direction, and an STI tap size of 5/8"-18. The inserts are made from 18-8 stainless steel, compatible with metal substrates, and use inch measurement.

Where to buy the HELI-COIL 5401-10 thread repair kit worldwide?

3G Electric supplies the HELI-COIL 5401-10 thread repair kit worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for a quote and lead time on this genuine HELI-COIL product.

How to install a HELI-COIL thread insert from the 5401-10 kit?

To install a HELI-COIL insert, drill out the damaged thread to the specified size, tap the hole using the included STI tap (5/8"-18), then wind the insert onto the installation tool and screw it into the tapped hole. Break off the tang after installation for a permanent repair.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates
