HELI-COIL Helical Insert: Tanged Tang Style, Free-Running, 1/4"-20 Thread Size, Plain - Free-Running Tanged Helical Inserts
HELI-COILFree-Running Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Free-Running, 1/4"-20 Thread Size, Plain

The HELI-COIL Helical Insert (MPN R1185-4) is a tanged tang style, free-running helical insert made of 18-8 metal. It features a 1/4"-20 inch coarse thread, right-hand orientation, and a tensile strength range of…

SKU 3G-OTH-598910

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Free-Running, 1/4"-20 Thread Size, Plain
Category
Free-Running Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
R1185-4
Type
Free-Running, Plain, Plain, 12 PK
Thread Size
1/4"-20
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HELI-COIL Helical Insert (MPN R1185-4) is a tanged tang style, free-running helical insert made of 18-8 metal. It features a 1/4"-20 inch coarse thread, right-hand orientation, and a tensile strength range of 200,000 to 250,000 psi, supplied in a 12-pack with a plain finish.

Frequently Asked Questions

What is a HELI-COIL helical insert used for?

A HELI-COIL helical insert repairs or reinforces threads in metal components. It provides a durable, free-running internal thread for fasteners, commonly used in automotive, aerospace, and industrial maintenance applications where stripped or worn threads need restoration.

What are the specifications of the HELI-COIL R1185-4 insert?

The HELI-COIL R1185-4 is a tanged, free-running helical insert with a 1/4"-20 inch coarse thread, right-hand orientation, made of 18-8 metal. It has a tensile strength of 200,000 to 250,000 psi and comes in a 12-pack with a plain finish.

Where to buy HELI-COIL helical inserts worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver the R1185-4 and other thread repair inserts to your facility, ensuring compliance with international shipping requirements.

How to install a HELI-COIL tanged helical insert?

To install a HELI-COIL tanged helical insert, drill out the damaged thread to the specified tap drill size, tap the hole with the correct HELI-COIL tap, then use the installation tool to wind the insert into the tapped hole. Break off the tang after installation for a permanent thread.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates
