HELI-COIL Helical Insert: Tangless Tang Style, Screw-Locking, #2-56 Thread Size - Screw-Locking Tangless Helical Inserts
HELI-COILScrew-Locking Tangless Helical Inserts

HELI-COIL Helical Insert: Tangless Tang Style, Screw-Locking, #2-56 Thread Size

HELI-COIL Tangless Tang Style Helical Insert, a screw-locking insert for #2-56 coarse threads in metal. Supplied in 100-piece packs, it features 18-8 material, dry film lubricant finish, and a tensile strength of…

SKU 3G-OTH-532460

Brand
HELI-COIL
Item
Helical Insert: Tangless Tang Style, Screw-Locking, #2-56 Thread Size
Category
Screw-Locking Tangless Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
AT3585-02CW086
Type
Screw-Locking, #2-56 Thread Size, 100 PK
Tensile Strength
200,000 to 250,000 psi
Finish Type
Dry Film Lubricant
Thread Type
Coarse
STI Tap Size
#2-56
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

HELI-COIL Tangless Tang Style Helical Insert, a screw-locking insert for #2-56 coarse threads in metal. Supplied in 100-piece packs, it features 18-8 material, dry film lubricant finish, and a tensile strength of 200,000 to 250,000 psi. This inch-system insert uses a right-hand thread and requires an STI tap size of #2-56.

Frequently Asked Questions

What is a HELI-COIL Tangless Tang Style helical insert used for?

A HELI-COIL Tangless Tang Style helical insert is used to repair or reinforce internal threads in metal components. It provides a strong, screw-locking thread for #2-56 coarse fasteners, ideal for applications requiring high tensile strength up to 250,000 psi.

What are the specifications of the HELI-COIL AT3585-02CW086 insert?

The HELI-COIL AT3585-02CW086 is a screw-locking, tangless helical insert for #2-56 coarse threads. It is made of 18-8 stainless steel with a dry film lubricant finish, has a tensile strength of 200,000 to 250,000 psi, and requires an STI tap size of #2-56. Supplied in 100-piece packs.

Where to buy HELI-COIL helical inserts in worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver the AT3585-02CW086 and other HELI-COIL products to your facility. Contact us for a quote and delivery options.

How to install a HELI-COIL tangless helical insert?

To install a HELI-COIL tangless helical insert, first drill and tap the hole to the specified STI tap size (#2-56). Use a tangless installation tool to insert the coil until it is slightly below the surface. The screw-locking feature secures the fastener without a separate locking element.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates
