HELI-COIL Helical Insert: Tangless Tang Style, Screw-Locking, 1/4"-20 Thread Size - Screw-Locking Tangless Helical Inserts
HELI-COILScrew-Locking Tangless Helical Inserts

HELI-COIL Helical Insert: Tangless Tang Style, Screw-Locking, 1/4"-20 Thread Size

The HELI-COIL Helical Insert is a screw-locking, tangless tang style insert with a 1/4"-20 coarse thread, plain finish, and 18-8 material grade. It offers a tensile strength of 200,000 to 250,000 psi, is compatible…

SKU 3G-OTH-532450

Brand
HELI-COIL
Item
Helical Insert: Tangless Tang Style, Screw-Locking, 1/4"-20 Thread Size
Category
Screw-Locking Tangless Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
AT3585-06C276
Type
Screw-Locking, Plain, 100 PK
Tensile Strength
200,000 to 250,000 psi
Finish Type
Plain
Thread Size
1/4"-20
Thread Type
Coarse
STI Tap Size
#6-32
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HELI-COIL Helical Insert is a screw-locking, tangless tang style insert with a 1/4"-20 coarse thread, plain finish, and 18-8 material grade. It offers a tensile strength of 200,000 to 250,000 psi, is compatible with metal, and comes in a 100-pack. This inch-system insert uses a #6-32 STI tap size and right-hand thread direction.

Frequently Asked Questions

What is a HELI-COIL screw-locking tangless helical insert used for?

A HELI-COIL screw-locking tangless helical insert repairs or reinforces tapped threads in metal, providing a durable 18-8 stainless steel thread that resists loosening under vibration. It is commonly used in automotive, aerospace, and industrial maintenance applications where thread integrity is critical.

What are the specifications of the HELI-COIL AT3585-06C276 insert?

The HELI-COIL AT3585-06C276 is a 1/4\"-20 coarse thread, screw-locking, tangless insert with a plain finish. It is made from 18-8 stainless steel, has a tensile strength of 200,000 to 250,000 psi, uses a #6-32 STI tap size, and comes in a 100-pack. Thread direction is right hand.

Where to buy HELI-COIL helical inserts worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide, handling full logistics and customs clearance for international orders. As a global industrial solutions provider, we source genuine HELI-COIL parts like the AT3585-06C276 and deliver them to your facility, regardless of location.

How to install a tangless helical insert?

To install a tangless helical insert, drill out the damaged thread to the specified STI tap size (#6-32 for this insert), tap the hole, then use a tangless installation tool to wind the insert into place. No tang to break off simplifies installation. Always follow the manufacturer's instructions for best results.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates
