HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, 5/16"-18 Thread Size - Screw-Locking Tanged Helical Inserts
HELI-COILScrew-Locking Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, 5/16"-18 Thread Size

The HELI-COIL Helical Insert is a tanged tang style, screw-locking insert in a plain finish, supplied in a 100-piece pack. It features a 5/16"-18 coarse, right-hand thread with an STI tap size of 5/16"-18, made from…

SKU 3G-OTH-529015

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Screw-Locking, 5/16"-18 Thread Size
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
A3585-5CN469
Type
Screw-Locking, Plain, 100 PK
Tensile Strength
200,000 to 250,000 psi
Finish Type
Plain
Thread Size
5/16"-18
Thread Type
Coarse
STI Tap Size
5/16"-18
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HELI-COIL Helical Insert is a tanged tang style, screw-locking insert in a plain finish, supplied in a 100-piece pack. It features a 5/16"-18 coarse, right-hand thread with an STI tap size of 5/16"-18, made from 18-8 material grade/class for metal compatibility. This inch-system insert offers a tensile strength of 200,000 to 250,000 psi (MPN A3585-5CN469).

Frequently Asked Questions

What is a HELI-COIL helical insert used for?

A HELI-COIL helical insert repairs or reinforces threads in metal. The screw-locking tang style prevents loosening under vibration, making it ideal for automotive, aerospace, and industrial maintenance applications where thread integrity is critical.

What are the specifications of the HELI-COIL A3585-5CN469 insert?

This HELI-COIL insert has a 5/16"-18 coarse thread, right-hand direction, and an STI tap size of 5/16"-18. It is made from 18-8 stainless steel with a tensile strength of 200,000 to 250,000 psi, supplied in a 100-piece pack with plain finish.

Where to buy HELI-COIL helical inserts in worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver genuine parts like the A3585-5CN469 to your facility, regardless of location.

How to install a tanged helical insert?

To install a HELI-COIL tanged insert, drill to the specified STI tap size (5/16"-18), tap the hole, then use a tang installation tool to wind the insert into place. After installation, break off the tang with a punch. Always follow the manufacturer's instructions for best results.
