Honeywell Non Plug-In Limit Switch: Roller Lever, Metallic, Momentary, Non Plug-In
The HONEYWELL LSM4N is a non plug-in limit switch from the HDLS series, featuring a rotary lever actuator with a metallic body style X. It offers momentary action with a pretravel of 18°, overtravel of 70°, total…
SKU 3G-OTH-29778
Need installation or engineering help?
Ask a question
Product Description
The HONEYWELL LSM4N is a non plug-in limit switch from the HDLS series, featuring a rotary lever actuator with a metallic body style X. It offers momentary action with a pretravel of 18°, overtravel of 70°, total travel of 80°, and differential travel of 10°.
Frequently Asked Questions
What is the Honeywell LSM4N limit switch used for?
The Honeywell LSM4N is a non plug-in limit switch from the HDLS series used to detect the presence or position of objects in industrial machinery. Its rotary lever actuator with 18° pretravel and 70° overtravel makes it suitable for conveyor systems, packaging equipment, and automated assembly lines requiring momentary contact.
What are the specifications of the Honeywell LSM4N?
The Honeywell LSM4N is a metallic, momentary, non plug-in limit switch with a rotary lever actuator. It has a pretravel of 18°, overtravel of 70°, total travel of 80°, and differential travel of 10°. It features 2NO/2NC contacts and is part of the HDLS series with body style X.
Where to buy the Honeywell LSM4N worldwide?
You can source the Honeywell LSM4N limit switch through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this HDLS series component.
How to install a Honeywell LSM4N limit switch?
Mount the Honeywell LSM4N securely using the metallic body style X housing. Ensure the rotary lever actuator aligns with the cam or target, allowing 18° pretravel and 70° overtravel. Wire the 2NO/2NC contacts per your control circuit. Test momentary action before full operation. Follow Honeywell's HDLS series guidelines for best results.
