Honeywell Actuator: Fire and Smoke Dampers, On/Off, Spring Return, 80 in-lb, 24V AC
The Honeywell MS8109F1010/U is a fire and smoke damper actuator with spring return, rated at 80 in-lb and 24V AC input. It features a 95° stroke with CW/CCW shaft rotation, hardwired electrical connection, and is…
SKU 3G-OTH-67024
Need installation or engineering help?
Ask a question
Product Description
The Honeywell MS8109F1010/U is a fire and smoke damper actuator with spring return, rated at 80 in-lb and 24V AC input. It features a 95° stroke with CW/CCW shaft rotation, hardwired electrical connection, and is compatible with building automation systems. This On/Off actuator does not include an auxiliary switch and is housed in a NEMA 1 / IP54 enclosure.
Frequently Asked Questions
What is the Honeywell MS8109F1010/U fire and smoke damper actuator used for?
The Honeywell MS8109F1010/U is an On/Off, spring return actuator designed for fire and smoke dampers in building automation systems. It provides 80 in-lb torque at 24V AC, with a 95° stroke and CW/CCW rotation, ensuring reliable damper closure during fire events.
What are the specifications of the Honeywell MS8109F1010/U actuator?
The Honeywell MS8109F1010/U is a 24V AC, On/Off spring return actuator rated at 80 in-lb. It features a 95° stroke, CW/CCW shaft rotation, hardwired connection, and a NEMA 1 / IP54 enclosure. It is building automation system compatible and does not include an auxiliary switch.
Where to buy the Honeywell MS8109F1010/U actuator worldwide?
3G Electric supplies the Honeywell MS8109F1010/U fire and smoke damper actuator to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery, ensuring you receive genuine Honeywell parts for your building automation needs.
How to install the Honeywell MS8109F1010/U spring return actuator?
Install the Honeywell MS8109F1010/U by mounting it to the damper shaft per the manufacturer's instructions. Ensure 24V AC power is supplied via hardwired connections, and verify the 95° stroke and CW/CCW rotation match damper requirements. Always follow local codes and safety guidelines for fire-rated installations.
