HUBBELL Pin and Sleeve Connector: Red, 277/480V AC, Three Phase, 30 A, 4 Pole, 5 Wire - Washdown-Rated Connectors
HUBBELLWashdown-Rated Connectors

HUBBELL Pin and Sleeve Connector: Red, 277/480V AC, Three Phase, 30 A, 4 Pole, 5 Wire

The HUBBELL Pin and Sleeve Connector (MPN HBL530C7W) is a washdown-rated connector designed for three-phase, 30 A, 277/480V AC applications with IEC grounding, featuring 4 poles and 5 wires. 3G Electric interprets…

SKU 3G-OTH-13186

Brand
HUBBELL
Item
Pin and Sleeve Connector: Red, 277/480V AC, Three Phase, 30 A, 4 Pole, 5 Wire
Category
Washdown-Rated Connectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HUBBELL
Manufacturer Part Number
HBL530C7W
Type
Three Phase, 30 A, IEC Grounding
AC
277/480V
Pole
4
Wire
5
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HUBBELL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HUBBELL Pin and Sleeve Connector (MPN HBL530C7W) is a washdown-rated connector designed for three-phase, 30 A, 277/480V AC applications with IEC grounding, featuring 4 poles and 5 wires. 3G Electric interprets this demand and delivers this genuine industrial connector, backed by our specialist expertise across 14 industrial departments, including electrical components.

Frequently Asked Questions

What is the HUBBELL Pin and Sleeve Connector used for?

The HUBBELL HBL530C7W is a washdown-rated pin and sleeve connector used for industrial power distribution in wet or washdown environments. It supplies 277/480V AC, three-phase, 30 A power through 4 poles and 5 wires with IEC grounding, common in food processing, automotive, and chemical plants.

What are the specifications of the HUBBELL HBL530C7W?

The HUBBELL HBL530C7W is a red pin and sleeve connector rated for 277/480V AC, three-phase, 30 A, with 4 poles and 5 wires. It features IEC grounding and is designed for washdown-rated applications. The brand is HUBBELL, and the manufacturer part number is HBL530C7W.

Where to buy the HUBBELL HBL530C7W worldwide?

3G Electric supplies the HUBBELL HBL530C7W pin and sleeve connector to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this washdown-rated connector.

How to install a HUBBELL pin and sleeve connector?

Installation of the HUBBELL HBL530C7W requires matching the connector to a compatible inlet or receptacle with the same voltage, amperage, and IEC grounding configuration. Ensure power is off, align the keyway, and fully insert until the locking ring engages. Follow local electrical codes and manufacturer guidelines for washdown-rated installations.
