IFM Pressure Transmitter: 0 psi to 30 psi, 0 to 10V DC, 4-Pin M12 Connector - Pressure Transmitters with 4-Pin M12 Connector
IFMPressure Transmitters with 4-Pin M12 Connector

IFM Pressure Transmitter: 0 psi to 30 psi, 0 to 10V DC, 4-Pin M12 Connector

The IFM PX9116 is a pressure transmitter with a 0 psi to 30 psi range and a 0 to 10V DC output, housed in a stainless steel body with a 4-pin M12 connector. It features a 1/4 in Male NPT process connection, an…

SKU 3G-OTH-176705

Brand
IFM
Item
Pressure Transmitter: 0 psi to 30 psi, 0 to 10V DC, 4-Pin M12 Connector
Category
Pressure Transmitters with 4-Pin M12 Connector
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

IFM
Manufacturer Part Number
PX9116
Series
PX
Type
IP65
DC
0 to 10V
Output
0 to 10V DC
Accuracy
±0.75%
Male NPT
1/4 in
IP Rating
IP65
Overpressure
290 psi
M12 Connector
4-Pin
Burst Pressure
725 psi
Housing Material
Stainless Steel
Process Connection Type
NPT
Process Connection Gender
Male
Calibration Certificate Included
No NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

IFM Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The IFM PX9116 is a pressure transmitter with a 0 psi to 30 psi range and a 0 to 10V DC output, housed in a stainless steel body with a 4-pin M12 connector. It features a 1/4 in Male NPT process connection, an accuracy of ±0.75%, an IP65 rating, an overpressure of 290 psi, and a burst pressure of 725 psi. This unit does not include a NIST-traceable calibration certificate.

Frequently Asked Questions

What is the IFM PX9116 pressure transmitter used for?

The IFM PX9116 pressure transmitter measures gauge pressure from 0 psi to 30 psi in industrial fluid and gas systems. Its 0 to 10V DC output integrates with PLCs and controllers for monitoring hydraulic, pneumatic, and process applications requiring a stainless steel, IP65-rated sensor.

What are the specifications of the IFM PX9116?

The IFM PX9116 has a 0 psi to 30 psi range, ±0.75% accuracy, 0 to 10V DC output, 4-pin M12 connector, 1/4 in male NPT process connection, IP65 rating, 290 psi overpressure, and 725 psi burst pressure. Housing is stainless steel; no NIST-traceable calibration certificate is included.

Where to buy the IFM PX9116 pressure transmitter worldwide?

3G Electric supplies the IFM PX9116 pressure transmitter worldwide. As a global industrial sourcing partner, we handle logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this 0 to 10V DC, 4-pin M12 connector model.

How to install the IFM PX9116 pressure transmitter?

Install the IFM PX9116 by threading the 1/4 in male NPT connection into a compatible port using PTFE tape on threads. Torque to manufacturer specifications. Connect the 4-pin M12 connector to a 0 to 10V DC input. Ensure the IP65 seal is intact and wiring matches the pinout diagram.

Used in

Common applications for IFM
Automotive assembly — IFM inductive proximity sensors (e.g., IFS243) for detecting metal parts on conveyor lines
Packaging machinery — IFM photoelectric sensors (e.g., OGE282) for object presence detection in high-speed wrapping systems
Hydraulic systems — IFM pressure transmitters (e.g., PX3227) for monitoring fluid pressure in industrial presses
Material handling — IFM RFID tags (e.g., E80347) for tracking pallets and containers in warehouse logistics
Machine safety — IFM light curtains (e.g., OY009S) for finger protection on automated assembly stations
Field wiring — IFM M12 connectors (e.g., E18163) for quick sensor replacement in food processing equipment

IFM Products

3G Electric supplies IFM pressure transmitters with 4-pin m12 connector. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
