IFM Solenoid Coil Connector: Form A, DIN 43650 Form A, 16 mm For Coil Size
The IFM Solenoid Coil Connector: Form A (SKU 787GE5, MPN E12224) is a DIN 43650 Form A connector with molded wires and a 3-pin configuration. It operates at 24V DC and includes an indicator light, though leads are…
SKU 3G-OTH-151202
Need installation or engineering help?
Ask a question
Product Description
The IFM Solenoid Coil Connector: Form A (SKU 787GE5, MPN E12224) is a DIN 43650 Form A connector with molded wires and a 3-pin configuration. It operates at 24V DC and includes an indicator light, though leads are not included. This connector is designed for use with 16 mm coil sizes.
Frequently Asked Questions
What is the IFM solenoid coil connector used for?
The IFM solenoid coil connector (MPN E12224) is used to electrically connect solenoid valves and actuators in industrial automation systems. It is designed for DIN 43650 Form A interfaces with a 16 mm coil size, operating at 24V DC. The molded wires and 3-pin configuration ensure reliable signal transmission, while the built-in indicator light simplifies troubleshooting.
What are the specifications of the IFM E12224 solenoid connector?
The IFM E12224 is a DIN 43650 Form A solenoid connector with molded wires and a 3-pin configuration. It operates at 24V DC and includes an indicator light for status monitoring. Leads are not included. The connector is designed for a 16 mm coil size and is rated for industrial environments. IFM is the OEM brand.
Where to buy the IFM solenoid coil connector worldwide?
You can source the IFM solenoid coil connector (MPN E12224) worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time. 3G Electric provides reliable sourcing for this DIN 43650 Form A connector.
How to install the IFM DIN 43650 Form A connector?
To install the IFM DIN 43650 Form A connector, first ensure the solenoid valve coil is 16 mm and power is off. Align the connector's 3-pin plug with the valve's receptacle, then tighten the center screw to secure. Connect the molded wires to your control system (leads not included). Verify the indicator light illuminates when 24V DC is applied.
