IFM Circular Connector: A Coded, 4 Pin, M12 Male Thread, IP67, Screw Terminals - Field-Wireable Industrial M12 Circular Connectors
IFMField-Wireable Industrial M12 Circular Connectors

IFM Circular Connector: A Coded, 4 Pin, M12 Male Thread, IP67, Screw Terminals

The IFM M12 Circular Connector (SKU 787GG5, MPN E12261) is a field-wireable industrial M12 circular connector with A coding for signal, low-power, and gigabit data applications. It features a 4-pin pin-type connector…

SKU 3G-OTH-10812

Brand
IFM
Item
Circular Connector: A Coded, 4 Pin, M12 Male Thread, IP67, Screw Terminals
Category
Field-Wireable Industrial M12 Circular Connectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

IFM
Manufacturer Part Number
E12261
Type
M12 Male Thread, IP67, Screw Terminals, Straight
Pin
4
Coding
A
IP Rating
IP67
Application
Signal
Thread Size
M12
Wiring Type
Screw Terminals
Mounting Type
Front Mounting
Mounting Style
Male Thread
Voltage Rating
250V DC
Connection Type
Gold-Plated Contacts
Housing Material
Zinc Die-Cast
Connector Body Type
Pin
Connector Application
A-Coded for Signal, Low-Power, and Gigabit Data
Connector Orientation
Straight
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

IFM Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The IFM M12 Circular Connector (SKU 787GG5, MPN E12261) is a field-wireable industrial M12 circular connector with A coding for signal, low-power, and gigabit data applications. It features a 4-pin pin-type connector body, straight orientation, screw terminals, and gold-plated contacts, with a voltage rating of 250V DC. The housing is zinc die-cast with an IP67 rating, and it uses M12 male thread for front mounting.

Frequently Asked Questions

What is the IFM M12 Circular Connector E12261 used for?

The IFM M12 Circular Connector E12261 is a field-wireable connector for signal, low-power, and gigabit data applications in industrial automation. Its A coding and IP67 rating suit sensor, actuator, and control system connections in harsh environments. 3G Electric supplies this connector globally.

What are the specifications of the IFM M12 Circular Connector E12261?

The IFM E12261 is a 4-pin, A-coded M12 male thread connector with screw terminals, straight orientation, and gold-plated contacts. It is rated IP67, 250V DC, with a zinc die-cast housing for front mounting. These specs ensure reliable signal and data transmission in industrial settings.

Where to buy the IFM M12 Circular Connector E12261 worldwide?

3G Electric supplies the IFM M12 Circular Connector E12261 to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this A-coded, IP67-rated connector.

How to install the IFM M12 Circular Connector E12261?

To install the IFM E12261, strip the cable, insert wires into screw terminals, and tighten. Ensure the M12 male thread is properly seated in the front-mount panel. Verify the IP67 seal is intact before tightening the coupling nut. 3G Electric can provide application support for this connector.

Used in

Common applications for IFM
Automotive assembly — IFM inductive proximity sensors (e.g., IFS243) for detecting metal parts on conveyor lines
Packaging machinery — IFM photoelectric sensors (e.g., OGE282) for object presence detection in high-speed wrapping systems
Hydraulic systems — IFM pressure transmitters (e.g., PX3227) for monitoring fluid pressure in industrial presses
Material handling — IFM RFID tags (e.g., E80347) for tracking pallets and containers in warehouse logistics
Machine safety — IFM light curtains (e.g., OY009S) for finger protection on automated assembly stations
Field wiring — IFM M12 connectors (e.g., E18163) for quick sensor replacement in food processing equipment

IFM Products

3G Electric supplies IFM field-wireable industrial m12 circular connectors. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
